Sunward SWL3210 Skid Steer Loader

Sunward SWL3210 Skid Steer Loader Specs front
Sunward SWL3210 Skid Steer Loader Specs front
Sunward SWL3210 Skid Steer Loader Specs side
Sunward SWL3210 Skid Steer Loader Specs side
Sunward SWL3210 Skid Steer Loader Specs back
Sunward SWL3210 Skid Steer Loader Specs back
Units

Dimensions

Dimensions

A

Length with Bucket

11.78 ft in

B

Width Over Tires

6.17 ft in

C

Height to Top of Cab

6.89 ft in

D

Wheelbase

3.67 ft in

E

Ground Clearance

8.08 in

F

Length w/o Bucket

9.03 ft in

G

Clearance at Max Lift and Dump

7.86 ft in

H

Reach at Max Lift and Dump

24.61 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2334

Engine Model

V3300DI

Net Power

73.7 hp

Power Measured @

2600 rpm

Operational

Operational Weight

7165.1 lb

Fuel Capacity

22.5 gal

Cooling System Fluid Capacity

2.3 gal

Engine Oil Fluid Capacity

3.5 gal

Hydraulic System Fluid Capacity

17.2 gal

Chain Box Fluid Capacity - each side

8 gal

Max Speed

7.9 mph

Tire Size

12-16.5

Loader

Breakout Force

5357.3

Operating Load Rating

2094.4 lb

Tipping Angle

4188.8 degrees

Bucket Capacity

0.7 yd3

Hydraulic

Pump Type

Gear

Pump Flow Capacity

33 gal/min

Relief Valve Pressure

3626 psi

Dimensions

Length with Bucket

11.8 ft in

Length w/o Bucket

9.1 ft in

Width Over Tires

6.2 ft in

Height to Top of Cab

6.9 ft in

Clearance at Max Lift and Dump

7.9 ft in

Wheelbase

3.7 ft in

Ground Clearance

8.1 in

Reach at Max Lift and Dump

24.7 in

Turning Radius from Center - machine rear

67 in

Turning Radius from Center - inc bucket

85.9 in
