Caterpillar 242B Series 3 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
11.28ft in
B
Width Over Tires
5.5ft in
E
Ground Clearance
7in
C
Height To Top Of Cab
6.63ft in
D
Wheelbase
3.59ft in
F
Length W/O Bucket
9.06ft in
G
Clearance At Max Lift And Dump
7.66ft in
H
Reach At Max Lift And Dump
24.49in
Length - With Bucket On Ground
135.31in
Length - Without Bucket
108.7in
Maximum Dump Angle
50 degrees
Maximum Reach - With Arms Parallel
48in
Rack Back Angle - Maximum Height
88 degrees
Reach - Maximum Lift/Dump
24in
Maximum Overall Height
154in
Bucket Pin Height - Carry Position
9in
Bucket Pin Height - Maximum Lift
10.09ft in
Bucket Pin Reach - Maximum Lift
10in
Bumper Overhang - Rear Axle
39in
Clearance At Maximum Lift And Dump
92in
Departure Angle
28 degrees
Height - Top Of Cab
6.59ft in
Turning Radius From Center - Inc Bucket
82.37in
Turning Radius From Center - Machine Rear
61.26in
Vehicle Width Over Tires
66in
Wheel Base
3.6ft in
Turn Radius From Center - Bucket
82in
Turn Radius From Center - Coupler
52in
Turn Radius From Center - Rear
61in
Operating Specifications
Rated Operating Capacity With Optional Counterweight
2200lb
Tipping Load
4300lb
Breakout Force - Tilt Cylinder
4507lb
Rated Operating Capacity
2150lb
Specifications
Engine
Engine Make
2236
Engine Model
C3.4DIT
Gross Power
74hp
Net Power
71hp
Displacement
201cu in
Bore
3.7in
Stroke
4.7in
Gross Power - Sae J1995
74hp
Engine Model
Cat 3.4 DIT
Net Power - Iso 9249 Eec
71hp
Net Power - Sae 1349
71hp
Net Flywheel Power
71hp
Operational
Operational Weight
7008lb
Fuel Capacity
15.4gal
Cooling System Fluid Capacity
2.7gal
Engine Oil Fluid Capacity
2.4gal
Max Speed
11.5mph
Hydraulic System Fluid Capacity
14.6gal
Chain Box Fluid Capacity - Each Side
1.6gal
Operating Speed
7.8mph
Operating Voltage
12V
Alternator Supplied Amperage
90amps
Power Train
Travel Speed Forward
7.7mph
Travel Speed Reverse
7.7mph
Travel Speed Reverse - 2-Speed Option
11.4mph
Travel Speed Forward - 2-Speed Option
11.4mph
Loader
Breakout Force
4507lb
Operating Load Rating
2150lb
Tipping Angle
4300degrees
Weights
Operating Weight
7008lb
Hydraulic
Pump Flow Capacity
22gal/min
Relief Valve Pressure
3335psi
Hydraulic System
Hydraulic Flow (1)
Standard
Hydraulic Power
42.8hp
Loader Hydraulic Pressure
3335 psi
Hydraulic Flow (2)
High Flow
Hydraulic Power - Calculated
60.3hp
Loader Hydraulic Flow (1)
22 gal/min
Loader Hydraulic Flow (2)
31 gal/min
Service Refill Capacities
Cooling System
2.6gal
Fuel Tank
15.3gal
Hydraulic Tank
9.2gal
Engine Crankcase
2.4gal
Hydraulic System
14.5gal
Chain Box - Each Side
1.6gal
Cab
Rops
SAE J1040 MAY94, ISO 3471:1994
Fops
SAE J1043 SEPT87, ISO 3449:1992 Level I
Fops Level Ii
SAE J231 JAN81, ISO 3449:1992 Level II
