New Holland W130BLR Wheel Loader

Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
MODEL.UNITS

Dimensions

Bucket

G

Dump Clearance At Max Raise

10.86ft in

Bucket Capacity - Struck

2.18yd3

Bucket Width

8.54ft in

Bucket Capacity - Heaped

2.57yd3

Dimensions

E

Ground Clearance

1.22ft in

A

Length With Bucket On Ground

25.11ft in

B

Width Over Tires

8.28ft in

C

Height To Top Of Cab

11.14ft in

D

Wheelbase

9.52ft in

F

Hinge Pin - Max Height

13.93ft in

H

Reach At Max Lift And Dump

3.07ft in


Specifications

Engine

Number Of Cylinders

6

Engine Model

FPT 667TA/EDB

Net Power

138hp

Gross Power

149hp

Power Measured @

2000rpm

Max Torque

508lb ft

Displacement

409cu in

Torque Measured @

1000rpm

Operational

Operating Weight

27723.2lb

Fuel Capacity

65gal

Hydraulic System Fluid Capacity

39gal

Engine Oil Fluid Capacity

3.5gal

Cooling System Fluid Capacity

9.6gal

Transmission Fluid Capacity

5gal

Front Axle/Diff Fluid Capacity

5.9gal

Rear Axle/Diff Fluid Capacity

5.9gal

Static Tipping Weight

19374.3lb

Turning Radius

19.5ft in

Operating Voltage

24V

Alternator Supplied Amperage

70amps

Tire Size

17.5x25 L2/L3

Transmission

Number Of Forward Gears

4

Number Of Reverse Gears

3

Max Speed - Forward

24mph

Max Speed - Reverse

15.6mph

Hydraulic System

Raise Time

6.3sec

Dump Time

1.3sec

Lower Time

4.7sec
