New Holland LS140 Skid Steer Loader

New Holland LS140 Skid Steer Loader Specs front
New Holland LS140 Skid Steer Loader Specs front
New Holland LS140 Skid Steer Loader Specs side
New Holland LS140 Skid Steer Loader Specs side
New Holland LS140 Skid Steer Loader Specs back
New Holland LS140 Skid Steer Loader Specs back
Units

Dimensions

Dimensions

A

Length with Bucket

9.98 ft in

B

Width Over Tires

4.11 ft in

C

Height to Top of Cab

6.11 ft in

D

Wheelbase

3.12 ft in

E

Ground Clearance

8.27 in

G

Clearance at Max Lift and Dump

7.26 ft in

H

Reach at Max Lift and Dump

25.2 in


Specifications

Engine

Number of Cylinders

3

Engine Make

2249

Engine Model

N843

Net Power

30 hp

Power Measured @

2900 rpm

Displacement

91.6 cu in

Operational

Operational Weight

4396.1 lb

Fuel Capacity

8.8 gal

Cooling System Fluid Capacity

2.5 gal

Engine Oil Fluid Capacity

1.5 gal

Hydraulic System Fluid Capacity

5 gal

Chain Box Fluid Capacity - each side

1.6 gal

Max Speed

6.8 mph

Tire Size

10x16.5

Operating Voltage

12 V

Alternator Supplied Amperage

40 amps

Loader

Breakout Force

3404

Operating Load Rating

1250.1 lb

Tipping Angle

2500.1 degrees

Bucket Capacity

0.5 yd3

Hydraulic

Pump Type

New Holland double acting

Pump Flow Capacity

10.8 gal/min

Relief Valve Pressure

2600 psi

Dimensions

Length with Bucket

10 ft in

Width Over Tires

4.2 ft in

Height to Top of Cab

6.2 ft in

Clearance at Max Lift and Dump

7.3 ft in

Wheelbase

3.2 ft in

Ground Clearance

8.3 in

Reach at Max Lift and Dump

25.2 in

Turning Radius from Center - machine rear

56.3 in

Turning Radius from Center - inc bucket

70.5 in
