Gehl 3935 Skid Steer Loader

Gehl 3935 Skid Steer Loader Specs front
Gehl 3935 Skid Steer Loader Specs front
Gehl 3935 Skid Steer Loader Specs side
Gehl 3935 Skid Steer Loader Specs side
Gehl 3935 Skid Steer Loader Specs back
Gehl 3935 Skid Steer Loader Specs back
Units

Dimensions

Dimensions

A

Length with Bucket

9.83 ft in

B

Width Over Tires

4.33 ft in

C

Height to Top of Cab

6.03 ft in

D

Wheelbase

3.03 ft in

E

Ground Clearance

8 in

F

Length w/o Bucket

7.5 ft in

G

Clearance at Max Lift and Dump

7.21 ft in

H

Reach at Max Lift and Dump

25 in


Specifications

Engine

Engine Make

2348

Engine Model

3TNE88 diesel

Net Power

36 hp

Power Measured @

3000 rpm

Displacement

100 cu in

Operational

Operational Weight

4600 lb

Fuel Capacity

8.6 gal

Hydraulic System Fluid Capacity

8.1 gal

Max Speed

6.9 mph

Tire Size

10.00x16.5

Operating Voltage

12 V

Alternator Supplied Amperage

40 amps

Loader

Operating Load Rating

1260 lb

Hydraulic

Pump Flow Capacity

14.4 gal/min

Dimensions

Length with Bucket

9.9 ft in

Length w/o Bucket

7.5 ft in

Width Over Tires

4.4 ft in

Height to Top of Cab

6.1 ft in

Clearance at Max Lift and Dump

7.3 ft in

Wheelbase

3.1 ft in

Ground Clearance

8 in

Reach at Max Lift and Dump

25 in

Turning Radius from Center - machine rear

40.3 in

Turning Radius from Center - inc bucket

35.6 in
