Merlo P 41.7 Top Telescopic Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
14.11ft in
E
Ground Clearance
1.86ft in
B
Width Over Tires
7.32ft in
C
Overall Height
8.13ft in
D
Wheelbase
9.03ft in
Turning Radius Outside Tires
13.29ft in
Lift
F
Max Lift Height
22.97ft in
G
Max Forward Reach
11.82ft in
Max Load At Max Reach
2976.25lb
Max Load At Max Height
9038.96lb
Max Lift Capacity
9038.96lb
Specifications
Engine
Number Of Cylinders
4
Engine Make
2349
Gross Power
140hp
Power Measured @
2400rpm
Aspiration
turbocharged aftercooler
Operational
Operating Weight
14903.3lb
Fuel Capacity
41gal
Hydraulic System Fluid Capacity
27.8gal
Operating Voltage
12V
Alternator Supplied Amperage
90amps
Tire Size
405/70-24
Transmission
Transmission Type
hydrostatic
Number Of Forward Gears
2
Max Speed - Forward
24.9mph
Hydraulic
Pump Type
load sensing
Pump Flow Capacity
39.7gal/min
Relief Valve Pressure
3045.8psi
