Manitou MA 470 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
14.82ft in
B
Overall Width
7.16ft in
C
Overall Height - Mast Lowered
11.19ft in
D
Wheelbase
8.54ft in
E
Ground Clearance
18.9in
F
Height To Top Of Overhead Guard
8.42ft in
G
Max Fork Height
13.13ft in
Turning Radius
16.38ft in
Mast
H
Mast Tip Forward
17degrees
I
Mast Tip Rear
12degrees
Max Fork Spread
68.9in
Lower Speed
_-
Load Center
23.63in
Load Capacity
15432.36lb
Lift Speed
_-
Specifications
Engine
Engine Make
2351
Engine Model
1104C.44 T
Power
100hp
Torque
303.9lb ft
Displacement
268.6cu in
Operational
Operating Weight
21318.8lb
Tire Type
18x22.5 XF
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
15.6mph
