Cukurova CF70 Forklift

Cukurova CF70 Forklift Specs front
Cukurova CF70 Forklift Specs front
Cukurova CF70 Forklift Specs side
Cukurova CF70 Forklift Specs side
Cukurova CF70 Forklift Specs back
Cukurova CF70 Forklift Specs back
Units

Dimensions

Dimensions

A

Length to Fork Face

11.65 ft in

B

Overall Width

6.91 ft in

C

Overall Height - mast lowered

8.5 ft in

D

Wheelbase

7.55 ft in

E

Ground Clearance

7.49 in

F

Height to Top of Overhead Guard

7.71 ft in

G

Max Fork Height

9.93 ft in

MAST

H

Mast Tip Forward

6 degrees

I

Mast Tip Rear

10 degrees


Specifications

Engine

Number of Cylinders

4

Engine Make

2351

Engine Model

1104C-44T

Power

100 hp

Torque

303.9 lb ft

Power Measured @

2200 rpm

Displacement

268.6 cu in

Torque Measured @

1400 rpm

Fuel Type

Diesel

Operational

Operating Weight

21318.7 lb

Tire Type

Pneumatic

Number of Front Wheels

4

Number of Rear Wheels

2

Max Speed

11.2 mph

MAST

Load Capacity

15432.4 lb

Load Center

23.7 in

Mast Tip Forward

6 degrees

Mast Tip Rear

10 degrees

Lift Speed

82.7 ft/min

Lower Speed

88.6 ft/min

Dimensions

Wheelbase

7.6 ft in

Length to Fork Face

11.7 ft in

Overall Width

7 ft in

Overall Height - mast lowered

8.5 ft in

Max Fork Height

10 ft in

Turning Radius

10.7 ft in

Height to Top of Overhead Guard

7.8 ft in

Ground Clearance

7.5 in

Right Angle Stack

17.3 ft in
