Link-Belt 600LX Material Handler

Units

Dimensions

Boom/Stick Option (MAT) 1

I

Max Height

60 ft in

J

Max Reach Along Ground

54.5 ft in

K

Max Depth

23 ft in

Dimensions

A

Shipping Length

37.78 ft in

B

Undercarriage Width

11.95 ft in

C

Shipping Height

11.97 ft in

E

Ground Clearance

2.48 ft in

L

Upperstructure Clearance

4.93 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2353

Engine Model

AA-6SD1XQB

Net Power

316 hp

Power Measured @

1950 rpm

Displacement

600 cu in

Aspiration

Turbocharged with Intercooler

Operational

Operating Weight w/o Attachment

119340 lb

Fuel Capacity

161.2 gal

Cooling System Fluid Capacity

12.1 gal

Engine Oil Capacity

8.8 gal

Hydraulic System Fluid Capacity

90.4 gal

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Swing Mechanism

Swing Torque

110710 lb ft

Swing Speed

9 rpm

Transmission

Transmission Type

Hydrostatic

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed

3.3 mph

Track Undercarriage

Shoe Size

29.6 in

Track Gauge

9.5 ft in

Number of Shoes per Side

50

Number of Track Rollers per Side

9

Length of Track on Ground

14.4 ft in

Hydraulic

Pump Type

2x Piston Pumps

Pump Capacity

4970 gal/min

Relief Pressure

190.2 psi

Dimensions

Shipping Length

37.8 ft in

Undercarriage Width

12 ft in

Shipping Height

12 ft in

Upperstructure Clearance

5 ft in

Ground Clearance

2.5 ft in

Boom/Stick Option (MAT) 1

Boom/Stick Option (MAT) 1

55\'0\" 2 Piece Boom

Max Reach Along Ground

54.5 ft in

Max Height

60 ft in

Max Depth

23 ft in
