Liebherr R996 Shovel

Liebherr R996 Shovel Specs side
Liebherr R996 Shovel Specs side
Liebherr R996 Shovel Specs back
Liebherr R996 Shovel Specs back
Liebherr R996 Shovel Specs extended_1
Liebherr R996 Shovel Specs extended_1
Liebherr R996 Shovel Specs extended_2
Liebherr R996 Shovel Specs extended_2
Liebherr R996 Shovel Specs extended_3
Liebherr R996 Shovel Specs extended_3
Units

Dimensions

Backhoe Boom / Stick 1

A

Overall Length

74.15 ft in

C

Height to Top of Boom

31.99 ft in

I

Max Cutting Height

54.47 ft in

J

Max Dump Height

34.45 ft in

M

Max Dig Depth

28.88 ft in

Q

Max Cutting Height

54.47 ft in

R

Max Dump Height

34.45 ft in

T

Max Dig Depth

28.88 ft in

Dimensions

B

Width Over Tracks

25.1 ft in

D

Length of Track on Ground

24.61 ft in

E

Ground Clearance

4.71 in

G

Height to Top of Cab

29.76 ft in

H

Tail Swing Radius

25.58 ft in

Loading Shovel

I

Max Cutting Height

- -

J

Max Dump Height

46.92 ft in

M

Max Dig Depth

- -

P

Height to Top of Boom - shovel

27.89 ft in

Q

Max Cutting Height

- -

R

Max Dump Height

46.92 ft in

S

Max Dig Reach

51.19 ft in

T

Max Dig Depth

- -

U

Overall Length - shovel

76.94 ft in

Undercarriage

F

Track Gauge

19.63 ft in

N

Loading Shovel Shoe Width

55.12 in


Specifications

Engine

Number of Cylinders

16

Engine Make

2347

Engine Model

2 x K 1800 E

Net Power

3000 hp

Power Measured @

1800 rpm

Displacement

3069.5 cu in

Aspiration

turbo-charged after-cooled

Operational

Fuel Capacity

3434.3 gal

Hydraulic System Fluid Capacity

2166.3 gal

Swing Speed

3.5 rpm

Operating Voltage

24 V

Alternator Supplied Amperage

150 amps

Undercarriage

Max Travel Speed

1.4 mph

Number of Upper Rollers

3

Number of Lower Rollers

7

Track Gauge

19.7 ft in

Backhoe Shoe Width 1

55.2 in

Backhoe Operating Weight - Shoe 1

1452846.4 lb

Backhoe Ground Pressure - Shoe 1

40 psi

Loading Shovel Shoe Width

55.2 in

Loading Shovel Operating Weight

1472687.9 lb

Loading Shovel Ground Pressure

40.9 psi

Backhoe Boom / Stick 1

Backhoe Boom / Stick

11.75m boom / 5m stick

Height to Top of Boom

32 ft in

Overall Length

74.2 ft in

Max Dig Depth

28.9 ft in

Max Cutting Height

54.5 ft in

Max Dump Height

34.5 ft in

Max Reach on Ground

65.7 ft in

Loading Shovel

Loading Shovel

8m boom / 5m stick

Height to Top of Boom - shovel

27.9 ft in

Overall Length - shovel

77 ft in

Max Dump Height

47 ft in

Max Dig Reach

51.2 ft in

Arm Crowd Force

516980 lb ft

Buckets

Reference Bucket Capacity

44.4 yd3

Minimum Bucket Capacity

37.9 yd3

Maximum Bucket Capacity

44.4 yd3

Dimensions

Width Over Tracks

25.1 ft in

Height to Top of Cab

29.8 ft in

Length of Tracks

32.9 ft in

Length of Track on Ground

24.7 ft in

Ground Clearance

4.8 in

Upper Structure Ground Clearance

9.4 ft in

Height of Tracks

9.8 ft in

Tail Swing Radius

25.6 ft in
