Liebherr R924B Hydraulic Excavator
Dimensions
Boom/Stick Option (Hex) 1
Shipping Length Of Unit
32.32ft in
Shipping Height Of Unit
10.06ft in
Max Cutting Height
30.19ft in
Max Loading Height
20.18ft in
Max Reach Along Ground
29.86ft in
Max Digging Depth
19.2ft in
Boom/Stick Option (Hex) 1
Boom 5900mm / Stick 1800mm
Boom/Stick Option (Hex) 2
Shipping Length Of Unit
32.16ft in
Max Cutting Height
31.01ft in
Shipping Height Of Unit
9.85ft in
Max Loading Height
21ft in
Max Reach Along Ground
31.5ft in
Max Digging Depth
21ft in
Boom/Stick Option (Hex) 2
Boom 5900mm / Stick 2400mm
Boom/Stick Option (Hex) 3
Shipping Length Of Unit
32.16ft in
Max Cutting Height
31.99ft in
Max Loading Height
21.99ft in
Shipping Height Of Unit
10.01ft in
Max Reach Along Ground
33.47ft in
Max Digging Depth
22.97ft in
Boom/Stick Option (Hex) 3
Boom 5900mm / Stick 3000mm
Boom/Stick Option (Hex) 4
Shipping Length Of Unit
32.16ft in
Shipping Height Of Unit
10.06ft in
Max Cutting Height
33.14ft in
Max Loading Height
22.97ft in
Max Reach Along Ground
35.6ft in
Max Digging Depth
25.27ft in
Boom/Stick Option (Hex) 4
Boom 5900mm / Stick 3700mm
Boom/Stick Option (Hex) 5
Shipping Length Of Unit
33.47ft in
Shipping Height Of Unit
9.85ft in
Max Cutting Height
34.95ft in
Max Loading Height
24.28ft in
Max Reach Along Ground
31.01ft in
Max Digging Depth
19.53ft in
Boom/Stick Option (Hex) 5
Boom 5900mm / Stick 1800mm
Boom/Stick Option (Hex) 6
Max Cutting Height
36.26ft in
Max Loading Height
25.76ft in
Shipping Length Of Unit
33.14ft in
Max Reach Along Ground
32.81ft in
Shipping Height Of Unit
9.52ft in
Max Digging Depth
21.33ft in
Boom/Stick Option (Hex) 6
Boom 5900mm / Stick 2400mm
Dimensions
Ground Clearance
1.55ft in
Height To Top Of Cab
10.06ft in
Width To Outside Of Tracks
9.85ft in
Length Of Track On Ground
12.57ft in
Tail Swing Radius
9.52ft in
Removal Counterweight Clearance
3.79ft in
Undercarriage
Track Gauge
1.97ft in
Shoe Size
23.63in
Max Travel Speed
3.24mph
Number Of Track Rollers Per Side
9
Number Of Carrier Rollers Per Side
2
Drawbar Pull
59349.57lb
Specifications
Engine
Number Of Cylinders
4
Engine Make
2245
Engine Model
D 924 Tl-E
Net Power
173hp
Power Measured @
2000rpm
Aspiration
turbo-charged and after-cooled reduced emissions
Displacement
402.8cu in
Operational
Operating Weight
57518.7lb
Fuel Capacity
95.2gal
Hydraulic System Fluid Capacity
116.3gal
Operating Voltage
24V
Alternator Supplied Amperage
55amps
Hydraulic System Relief Valve Pressure
5076.4psi
Hydraulic Pump Flow Capacity
113.1gal/min
Swing Mechanism
Swing Torque
54.6lb ft
Swing Speed
8rpm
Buckets
Reference Bucket Capacity
1.4yd3
Minimum Bucket Capacity
0.4yd3
Maximum Bucket Capacity
2.4yd3
