Liebherr LTM1500-8.1 (84M) All Terrain Crane

Liebherr LTM1500-8.1 (84M) All Terrain Crane Specs front
Liebherr LTM1500-8.1 (84M) All Terrain Crane Specs front
Liebherr LTM1500-8.1 (84M) All Terrain Crane Specs side
Liebherr LTM1500-8.1 (84M) All Terrain Crane Specs side
Liebherr LTM1500-8.1 (84M) All Terrain Crane Specs extend
Liebherr LTM1500-8.1 (84M) All Terrain Crane Specs extend
Units

Dimensions

Boom

I

Min Height @ Max Raise Angle

52.83 ft in

J

Max Height @ Max Raise Angle - no jib

275.6 ft in

K

Min Working Radius

16.41 ft in

L

Max Working Radius

255.91 ft in

M

Max Elevating Angle

83 degrees

Dimensions

A

Transport Length

68.8 ft in

B

Transport Width

20.51 ft in

C

Transport Height

12.96 ft in

F

Width w/ Outriggers Extended

- -

G

Carrier Length

61.13 ft in

H

Upper Structure Tail Swing Radius

19.74 ft in


Specifications

UPPER STRUCTURE ENGINE

Make

Liebherr

Model

D936L A6

Net Power

326 hp

Max Torque

1500 lb ft

CARRIER ENGINE

Make

Liebherr

Model

D9508 A7

Net Power

680 hp

Max Torque

3000 lb ft

Operational

Number of Axels

8

Carrier Fuel Capacity

158.6 gal

Operating Voltage

24 V

Alternator Supplied Amperage

170 amps

Tire Size

14R25

Transmission

Transmission Type

automatic with torque converter ZF TC-tronic

Number of Forward Gears

12

Number of Reverse Gears

2

Max Speed - Forward

46.7 mph

Max Speed - Reverse

4.5 mph

Boom

Number of Sections

7

Min Height @ Max Raise Angle

52.9 ft in

Max Height @ Max Raise Angle - no jib

275.6 ft in

Max Elevating Angle

83 degrees

Max Lift Capacity

1102311.4 lb

Min Working Radius

16.5 ft in

Max Working Radius

256 ft in

Swing Speed

1 rpm

Dimensions

Transport Length

68.8 ft in

Transport Width

20.6 ft in

Transport Height

13 ft in

Carrier Length

61.2 ft in

Upper Structure Tail Swing Radius

19.8 ft in
