Liebherr L550 XPOWER Wheel Loader

Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
MODEL.UNITS

Dimensions

Bucket

G

Dump Clearance At Max Raise

9.5ft in

Arm Length

8.6ft in

Breakout Force

28101.12lb

Bucket Capacity - Heaped

3.9yd3

Bucket Width

8.1ft in

Digging Depth

3ft in

Dimensions

E

Ground Clearance

1.7ft in

A

Length With Bucket On Ground

28.1ft in

C

Height To Top Of Cab

11.1ft in

D

Wheelbase

11.2ft in

F

Hinge Pin - Max Height

13.4ft in

H

Reach At Max Lift And Dump

3.9ft in


Specifications

Electrical System

Alternator

28/140 (V/A)

Voltage

24 VV

Starter

24/10.5 (V/HP)

Battery

2 x 180 Ah

Engine

Fuel Injection

Electronic Common Rail high-pressure injection

Number Of Cylinders

4

Engine Model

D934 A7

Net Power

188hp

Air Cleaner

Dry type filter with main and safety element, pre-cleaner, service indicator on the Liebherr display

Gross Power

192hp

Power Measured @

1800rpm

Max Torque

896 lb ft

Displacement

428cu in

Torque Measured @

1100rpm

Aspiration

Water-cooled in-line engine with charge-air cooling, exhaust after-treatment through Liebherr-SCR technology

Bore

4.8in

Stroke

6in

Operational

Operating Weight

39020lb

Fuel Capacity

74gal

Hydraulic System Fluid Capacity

46.2gal

Engine Oil Fluid Capacity

6.9gal

Cooling System Fluid Capacity

17.7gal

Hydraulic Fluid Capacity

27.7gal

Front Axle/Diff Fluid Capacity

9.2gal

Rear Axle/Diff Fluid Capacity

9.2gal

Static Tipping Weight

26895lb

Turning Radius

21.9ft in

Tire Size

23.5R25 L3

Hydraulic System

Max Operating Pressure

4786 psi

Relief Valve Setting

4351.2psi

Pump Flow Capacity

62gal/min

Raise Time

5.5sec

Dump Time

2.3sec

Lower Time

2.7sec

Pump Type

“Load-sensing” variable axial piston pump with output and flow control, and pressure cut-off in the control block
