Liebherr A904CHD Material Handler

Units

Dimensions

Boom/Stick Option (MAT) 1

I

Max Height

39.38 ft in

J

Max Reach Along Ground

33.8 ft in

K

Max Depth

7.22 ft in

Boom/Stick Option (MAT) 2

I

Max Height

42.66 ft in

J

Max Reach Along Ground

37.08 ft in

K

Max Depth

10.5 ft in

Boom/Stick Option (MAT) 3

I

Max Height

31.83 ft in

J

Max Reach Along Ground

37.73 ft in

K

Max Depth

16.08 ft in

Dimensions

A

Shipping Length

31.5 ft in

B

Undercarriage Width

9.03 ft in

C

Shipping Height

10.62 ft in

E

Ground Clearance

1.17 ft in

L

Upperstructure Clearance

4.3 ft in

Wheel Undercarriage

D

Wheelbase

9.19 ft in

F

Width w/ Stabilizers on Ground

13.95 ft in


Specifications

Engine

Engine Make

2245

Engine Model

D 934 S

Gross Power

143 hp

Displacement

390.6 cu in

Aspiration

turbo-charged and after-cooled reduced emissions

Operational

Operating Weight w/o Attachment

53800 lb

Fuel Capacity

92.5 gal

Hydraulic System Fluid Capacity

46.3 gal

Operating Voltage

24 V

Alternator Supplied Amperage

80 amps

Swing Mechanism

Swing Torque

Swing Speed

9 rpm

Transmission

Max Speed

12.5 mph

Wheel Undercarriage

Tire Size

10.00-20

Wheelbase

9.2 ft in

Width w/ Stabilizers on Ground

14 ft in

Hydraulic

Pump Type

Liebherr variable displacement swashplate double pump

Pump Capacity

50 gal/min

Dimensions

Shipping Length

31.5 ft in

Undercarriage Width

9.1 ft in

Shipping Height

10.7 ft in

Upperstructure Clearance

4.3 ft in

Ground Clearance

1.2 ft in

Boom/Stick Option (MAT) 1

Boom/Stick Option (MAT) 1

6.6m boom / 4m stick

Max Reach Along Ground

33.8 ft in

Max Height

39.4 ft in

Max Depth

7.3 ft in

Boom/Stick Option (MAT) 2

Boom/Stick Option (MAT) 2

6.6m boom / 5m stick

Max Reach Along Ground

37.1 ft in

Max Height

42.7 ft in

Max Depth

10.5 ft in

Boom/Stick Option (MAT) 3

Boom/Stick Option (MAT) 3

6.6m boom / 4m stick and grapple model 65

Max Reach Along Ground

37.8 ft in

Max Height

31.9 ft in

Max Depth

16.1 ft in
