Fuchs MHL331 Material Handler
Units
Dimensions
Dimensions
D
Wheelbase
8.2ft in
E
Ground Clearance
1.2ft in
Overall Length
15.1ft in
Turning Radius
25.11ft in
Overall Width
8.20 Ft in
Overall Height
10.1ft in
Wheel Undercarriage
Steering Angle
29degrees
Specifications
Electrical System
Alternator
28V / 100A
Batteries
2 × 12V / 110Ah/ 750A (according to EN)
Operation Voltage
24V
Lighting
2 × LED headlamps, turn indicators and tail lights
Engine
Cooling Method
Water and charge air cooling with temperature controlled fan speed
Engine Model
Deutz TCD 4.1 L4
Engine Type
4-cylinder in-line engine
Gross Power
154hp
Power Measured @
2000rpm
Displacement
250cu in
Operational
Def Tank Capacity
8.5gal
Gradeability-Laden
40%
Operating Weight W/O Attachment
53351lb
Fuel Capacity
69gal
Hydraulic System Fluid Capacity
86gal
Swing Mechanism
Swing Speed
7.5rpm
Transmission
Max Speed
11.2mph
Hydraulic
Maximum Operating Pressure
5221psi
