Kubota L6060HSTCC MFWD Tractor

MFWD Tractor
MFWD Tractor
MFWD Tractor
MFWD Tractor
MFWD Tractor
MFWD Tractor
Units

Dimensions

Dimensions

A

Overall Length

126.38in

B

Overall Width

5.62ft in

D

Wheelbase

6.29ft in

E

Ground Clearance

15.44in


Specifications

Engine

Number of Cylinders

4

Engine Make

KUBOTA

Engine Model

L6060HSTCC

Engine Type

E-TVCS, indirect injection, vertical, liquid-cooled 4-cycle diesel

Net Power

60hp

Gross Power

62hp

PTO Power

53hp

Rated Speed

2700rpm

Displacement

148.5cu in

Aspiration

Natural with EGR

Bore

3.5in

Stroke

4.1in

Operational

Operating Weight

4376.2lb

Fuel Capacity

13.5gal

3 Point Hitch Type

Category 1 & 2

3 Point Hitch Lift Capacity @ 24 inches

2976.3lb

Turning Radius

9.2ft in

Tire Size Front - 2wd / 4wd

9.5 - 16

Rear Tires Size 2wd/4wd

14.9 - 26

Operating Voltage

12V

Alternator Supplied Amperage

60amps

Power Take-Off(PTO)

Mid- PTO

1 speed: 2000 rpm

Rear PTO

1 speed: 540 rpm

Power Take-Off(PTO) Type

Independent

Transmission

Brakes

Wet disc type

Steering

Hydrostatic power steering

Clutch, wet/dry

Dry type single stage

Transmission Type

HST Plus

Number of Forward Gears

6

Number of Reverse Gears

6

Max Speed

16.9mph

Hydraulic System

Implement Pump Flow PS

9.4gal/min

Pump Flow Capacity

4.7gal/min

Number of Remote Control Valves

2

Dimensions

Wheelbase

6.3ft in

Rear Tread Range

52.2-56.3 in, 1325-1430 mm

Front Tread Range

52.8in

Overall Length

126.4in

Overall Width

5.7ft in

Height with ROPS

7.8ft in

Ground Clearance

15.5in
