Kubota L5460HSTCC MFWD Tractor
Units
Dimensions
Dimensions
A
Overall Length
126.38in
D
Wheelbase
6.29ft in
B
Overall Width
5.62ft in
E
Ground Clearance
15.44in
Height With Rops
7.71ft in
Front Tread Range
52.76in
Rear Tread Range
52.2-56.3 in, 1325-1430 mm
Specifications
Engine
Number Of Cylinders
4
Engine Make
KUBOTA
Engine Model
L5460HSTCC
Engine Type
E-TVCS, indirect injection, vertical, liquid-cooled 4-cycle diesel
Gross Power
56hp
Net Power
54hp
Pto Power
46.5hp
Rated Speed
2600rpm
Displacement
148.5cu in
Aspiration
Natural with EGR
Bore
3.5in
Stroke
4.1in
Operational
Operating Weight
4376.2lb
Fuel Capacity
13.5gal
3 Point Hitch Type
Category 1 & 2
3 Point Hitch Lift Capacity @ 24 Inches
2976.3lb
Turning Radius
9.2ft in
Tire Size Front - 2wd / 4wd
9.5 - 16
Rear Tires Size 2wd/4wd
14.9 - 26
Operating Voltage
12V
Alternator Supplied Amperage
60amps
Power Take-Off(Pto)
Mid- Pto
1 speed: 2000 rpm
Rear Pto
1 speed: 540 rpm
Power Take-Off(Pto) Type
Independent
Transmission
Brakes
Wet disc type
Steering
Hydrostatic power steering
Clutch, Wet/Dry
Dry type single stage
Transmission Type
HST Plus
Number Of Forward Gears
6
Number Of Reverse Gears
6
Max Speed
16.9mph
Hydraulic System
Implement Pump Flow Ps
9.4gal/min
Pump Flow Capacity
4.7gal/min
Number Of Remote Control Valves
2
