Krause 7400-21NR Disc

Krause 7400-21NR Disc Specs side
Krause 7400-21NR Disc Specs side
Krause 7400-21NR Disc Specs back
Krause 7400-21NR Disc Specs back
Krause 7400-21NR Disc Specs extended
Krause 7400-21NR Disc Specs extended
Units

Dimensions

Dimensions

B

Transport Width

10.92 ft in

C

Transport Height

11.58 ft in


Specifications

Disc System

Spacing #1

8 in

Blade Diameter

22 in

Depth Control

Remote Stop Valve

Gangs

Front Disk Angle

19 degrees

Rear Disk Angle

17 degrees

Bearing Type

Regreaseable SuperSeal

Scrapers

5\" wide

Dimensions

Working Width Spacing #1 min

21.2 ft in

Transport Width

11 ft in

Transport Height

11.6 ft in

Min Weight

9774 lb

Max Weight

10171 lb

Main Frame Tires

11L x 15\" 8-ply

Wing Tires

11L x 15\" 8-ply
