Komatsu PC600-7 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
42.02ft in
C
Shipping Height Of Unit
14.1ft in
I
Max Cutting Height
38.98ft in
J
Max Loading Height
26.12ft in
K
Max Reach Along Ground
42ft in
L
Max Vertical Wall Digging Depth
24.64ft in
M
Max Digging Depth
27.86ft in
Boom/Stick Option (Hex) 1
boom 7660mm w/ arm 3500mm
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
38.81ft in
I
Max Cutting Height
36.55ft in
C
Shipping Height Of Unit
15.09ft in
J
Max Loading Height
23.66ft in
K
Max Reach Along Ground
37.08ft in
L
Max Vertical Wall Digging Depth
18.48ft in
M
Max Digging Depth
23.17ft in
Boom/Stick Option (Hex) 2
boom 6600mm w/ arm 2900
Dimensions
E
Ground Clearance
2.56ft in
G
Height To Top Of Cab
10.8ft in
B
Width To Outside Of Tracks
12.79ft in
D
Length Of Track On Ground
15.1ft in
H
Tail Swing Radius
12.47ft in
Removal Counterweight Clearance
4.48ft in
Undercarriage
F
Track Gauge
8.5ft in
N
Shoe Size
23.63in
Number Of Shoes Per Side
49
Drawbar Pull
93255.5lb
Number Of Track Rollers Per Side
8
Number Of Carrier Rollers Per Side
3
Max Travel Speed
3.05mph
Ground Pressure
14.5psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2238
Engine Model
SA6D140E-3
Net Power
385hp
Power Measured @
1800rpm
Displacement
930.1cu in
Aspiration
Turbocharged with aftercooler
Operational
Operating Weight
124520lb
Fuel Capacity
232.5gal
Cooling System Fluid Capacity
15.1gal
Hydraulic System Fluid Capacity
95.2gal
Engine Oil Capacity
9.8gal
Swing Drive Fluid Capacity
3.5gal
Hydraulic System Relief Valve Pressure
4978.2psi
Hydraulic Pump Flow Capacity
216.7gal/min
Swing Mechanism
Swing Speed
8.3rpm
Buckets
Reference Bucket Capacity
3.6yd3
Minimum Bucket Capacity
3.2yd3
Maximum Bucket Capacity
4.6yd3
