Komatsu PC30-1 Mini Excavator

Komatsu PC30-1 Mini Excavator Specs front
Komatsu PC30-1 Mini Excavator Specs front
Komatsu PC30-1 Mini Excavator Specs side
Komatsu PC30-1 Mini Excavator Specs side
Komatsu PC30-1 Mini Excavator Specs extended
Komatsu PC30-1 Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

16.02 ft in

C

Shipping Height of Unit

7.67 ft in

I

Max Cutting Height

12.98 ft in

J

Max Loading Height

8.68 ft in

K

Max Reach Along Ground

15.92 ft in

L

Max Vertical Wall Digging Depth

7.08 ft in

M

Max Digging Depth

10.04 ft in

Dimensions

B

Width to Outside of Tracks

5.17 ft in

D

Length of Track on Ground

5.17 ft in

E

Ground Clearance

1.01 ft in

G

Height to Top of Cab

7.67 ft in

H

Tail Swing Radius

4.76 ft in

Undercarriage

F

Track Gauge

4.6 ft in

N

Shoe Size

11.82 in


Specifications

Engine

Engine Make

2238

Engine Model

3D84-IB

Gross Power

26.2 hp

Displacement

86.2 cu in

Operational

Operating Weight

7050 lb

Fuel Capacity

10.6 gal

Hydraulic System Fluid Capacity

13.3 gal

Hydraulic System Relief Valve Pressure

2490 psi

Hydraulic Pump Flow Capacity

25.1 gal/min

Swing Mechanism

Swing Speed

13 rpm

Undercarriage

Shoe Size

11.9 in

Ground Pressure

3.8 psi

Max Travel Speed

1.4 mph

Track Gauge

4.6 ft in

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Stick 4'6" (1365mm)

Shipping Height of Unit

7.7 ft in

Shipping Length of Unit

16.1 ft in

Max Digging Depth

10.1 ft in

Max Reach Along Ground

16 ft in

Max Cutting Height

13 ft in

Max Loading Height

8.7 ft in

Max Vertical Wall Digging Depth

7.1 ft in

Dimensions

Width to Outside of Tracks

5.2 ft in

Height to Top of Cab

7.7 ft in

Ground Clearance

1.1 ft in

Removal Counterweight Clearance

1.9 ft in

Tail Swing Radius

4.8 ft in

Length of Track on Ground

5.2 ft in
