Komatsu PC25R-8 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
14.87ft in
I
Max Cutting Height
14.31ft in
C
Shipping Height Of Unit
8.04ft in
J
Max Loading Height
10.09ft in
K
Max Reach Along Ground
14.77ft in
L
Max Vertical Wall Digging Depth
7.06ft in
M
Max Digging Depth
8.37ft in
Boom/Stick Option (Hex) 1
Boom 7'3" (2220mm)/Stick 3'8" (1120mm)
Boom/Stick Option (Hex) 2
I
Max Cutting Height
15.16ft in
A
Shipping Length Of Unit
14.98ft in
J
Max Loading Height
10.9ft in
C
Shipping Height Of Unit
8.04ft in
K
Max Reach Along Ground
16.02ft in
L
Max Vertical Wall Digging Depth
8.57ft in
M
Max Digging Depth
9.26ft in
Boom/Stick Option (Hex) 2
Boom 7'3" (2220mm)/Stick 4'8" (1420mm)
Dimensions
B
Width To Outside Of Tracks
4.93ft in
D
Length Of Track On Ground
4.88ft in
E
Ground Clearance
0.96ft in
G
Height To Top Of Cab
8.03ft in
H
Tail Swing Radius
4.11ft in
Removal Counterweight Clearance
1.89ft in
Undercarriage
N
Shoe Size
11.82in
F
Track Gauge
3.94ft in
Max Travel Speed
2.99mph
Ground Pressure
3.8psi
Specifications
Engine
Number Of Cylinders
3
Engine Make
2238
Engine Model
3D82AE
Gross Power
23.8hp
Power Measured @
2400rpm
Displacement
81.2cu in
Operational
Operating Weight
5842.3lb
Fuel Capacity
9.3gal
Hydraulic System Fluid Capacity
7.7gal
Hydraulic System Relief Valve Pressure
2990psi
Hydraulic Pump Flow Capacity
17.5gal/min
Swing Mechanism
Swing Speed
8.9rpm
Buckets
Reference Bucket Capacity
0.2yd3
Minimum Bucket Capacity
0.1yd3
Maximum Bucket Capacity
0.2yd3
