Komatsu HA270-3 Articulated Dump Truck
Units
Dimensions
Dimensions
A
Overall Length
30.52ft in
B
Overall Width
8.7ft in
C
Overall Height
11.23ft in
D
Wheelbase
13.08ft in
E
Ground Clearance
1.66ft in
F
Dump Height
20.84ft in
Dump
Capacity - Heaped
21.06yd3
Rated Payload
59524.82lb
Specifications
Engine
Number Of Cylinders
6
Engine Make
2238
Engine Model
S6D125
Gross Power
248.1hp
Net Power
240hp
Power Measured @
2200rpm
Displacement
671.3cu in
Operational
Fuel Capacity
66.1gal
Tire Size
23.5-25
Transmission
Number Of Forward Gears
6
Max Speed
32.4mph
Weights
Front Axle - Empty
19731.4lb
Rear Axle - Empty
19731.4lb
Front Axle - Loaded
33289.9%
Rear Axle - Loaded
65697.8lb
Total Empty
39462.8lb
Total Loaded
98987.6lb
