Komatsu H135S Shovel

Komatsu H135S Shovel Specs side
Komatsu H135S Shovel Specs side
Komatsu H135S Shovel Specs back
Komatsu H135S Shovel Specs back
Komatsu H135S Shovel Specs extended_1
Komatsu H135S Shovel Specs extended_1
Komatsu H135S Shovel Specs extended_2
Komatsu H135S Shovel Specs extended_2
Komatsu H135S Shovel Specs extended_3
Komatsu H135S Shovel Specs extended_3
Units

Dimensions

Dimensions

B

Width Over Tracks

16.77 ft in

D

Length of Track on Ground

16.02 ft in

E

Ground Clearance

30.6 in

G

Height to Top of Cab

20.45 ft in

H

Tail Swing Radius

16.21 ft in

Loading Shovel

I

Max Cutting Height

44.3 ft in

J

Max Dump Height

31.83 ft in

M

Max Dig Depth

9.85 ft in

P

Height to Top of Boom - shovel

21.33 ft in

Q

Max Cutting Height

44.3 ft in

R

Max Dump Height

31.83 ft in

S

Max Dig Reach

38.06 ft in

T

Max Dig Depth

9.85 ft in

U

Overall Length - shovel

35.77 ft in

Undercarriage

F

Track Gauge

13.95 ft in

N

Loading Shovel Shoe Width

23.63 in


Specifications

Engine

Number of Cylinders

12

Engine Make

2347

Engine Model

VTA28-C-800

Net Power

728 hp

Power Measured @

1800 rpm

Displacement

1709 cu in

Aspiration

Turbocharged

Operational

Fuel Capacity

475.6 gal

Hydraulic System Fluid Capacity

425.4 gal

Swing Speed

6.2 rpm

Undercarriage

Max Travel Speed

1.5 mph

Track Gauge

14 ft in

Loading Shovel Shoe Width

23.7 in

Loading Shovel Operating Weight

308647.2 lb

Loading Shovel Ground Pressure

29.3 psi

Loading Shovel

Height to Top of Boom - shovel

21.4 ft in

Overall Length - shovel

35.8 ft in

Max Dig Depth

9.9 ft in

Max Cutting Height

44.3 ft in

Max Dump Height

31.9 ft in

Max Dig Reach

38.1 ft in

Buckets

Reference Bucket Capacity

12.5 yd3

Minimum Bucket Capacity

4 yd3

Maximum Bucket Capacity

12.5 yd3

Dimensions

Width Over Tracks

16.8 ft in

Height to Top of Cab

20.5 ft in

Length of Tracks

21.2 ft in

Length of Track on Ground

16.1 ft in

Ground Clearance

30.6 in

Upper Structure Ground Clearance

6.4 ft in

Tail Swing Radius

16.3 ft in


Compare similar models

Manufacturer / Model

Net Power

Loading Shovel Operating Weight

Loading Shovel Ground Pressure

Net Power

710 hp

Loading Shovel Operating Weight

272932.3 lb

Loading Shovel Ground Pressure

26.2 psi
