John Deere JD670 Motor Grader

Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Motor Grader
Units

Dimensions

Dimensions

A

Overall Length

27.27ft in

B

Width Over Tires

7.68ft in

D

Wheelbase

19.59ft in

G

Tandem Axle Wheelbase

5.06ft in

F

Front Ground Clearance

1.84ft in

H

Blade Base

8.34ft in

Height To Top Of Isomount Cab

10.5ft in


Specifications

Engine

Number Of Cylinders

6

Engine Make

2240

Power Measured @

2300rpm

Torque Measured @

1300rpm

Max Power

125hp

Net Power Gears 7-8

125hp

Net Torque Gears 7-8

372lb ft

Displacement

414cu in

Aspiration

Turbocharged

Operational

Std Operation Weight - Front Axle

7653lb

Std Operation Weight - Rear Axle

18177lb

Hydraulic System Fluid Capacity

28gal

Std Operation Weight - Total

25830lb

Max Operation Weight - Front Axle

7970lb

Max Operation Weight - Rear Axle

21474lb

Max Operation Weight - Total

29444lb

Oil System Fluid Capacity

5gal

Fuel Capacity

60gal

Cooling System Fluid Capacity

7gal

Circle Gearbox Fluid Capacity

3gal

Tandem Case Fluid Capacity (Each)

4gal

Tire Size

13.00-24

Operating Voltage

24V

Steering

Articulation Angle

25degrees

Turning Radius

22.1ft in

Transmission

Transmission Type

Power Shift

Number Of Gears - Forward

8

Number Of Gears - Reverse

4

Max Speed - Forward

23.9mph

Max Speed - Reverse

7.6mph

Front Axle

Wheel Lean

20degrees

Oscillation - Total

30degrees

Ground Clearance

1.9ft in

Moldboard

Moldboard Width

12ft in

Moldboard Height

24in

Moldboard Thickness

0.9in

Side Shift Left

26.9in

Side Shift Right

26.9in

Hydraulic System

Pump Type

Colsed Center Variable Displacement

Pump Flow

35gal/min

Relief Valve Pressure

2250psi

Circle

Diameter

57.9in

Rotation

360degrees

Max Reach Outside Tires - Left

83.9in

Max Reach Outside Tires - Right

83.9in

Max Lift Above Ground

16.2in

Blade Tip Angle - Front

35degrees
