John Deere 950J LGP Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
19.5ft in
B
Width Over Tracks
10.17ft in
C
Height To Top Of Cab
11.49ft in
D
Length Of Track On Ground
10.92ft in
E
Ground Clearance
1.75ft in
Undercarriage
G
Track Gauge
7.17ft in
H
Standard Shoe Size
36in
Number Of Track Rollers Per Side
8
Ground Pressure
6.5psi
Number Of Shoes Per Side
43
Ground Contact Area
9396in2
Track Pitch
8.5in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2245
Engine Model
D 936-L A6
Net Power
247hp
Power Measured @
1600rpm
Max Torque
937lb ft
Displacement
641cu in
Torque Measured @
1400rpm
Aspiration
Turbocharger w/ intercooler
Operational
Operating Weight
59255lb
Fuel Capacity
141gal
Cooling System Fluid Capacity
16.4gal
Engine Oil Capacity
11.4gal
Hydraulic Fluid Capacity
50gal
Powertrain Fluid Capacity
50gal
Final Drives Fluid Capacity
5.2gal
Operating Voltage
24V
Alternator Supplied Amperage
80amps
Transmission
Transmission Type
Hydrostatic with direct drive
Max Speed - Forward
6.8mph
Max Speed - Reverse
6.8mph
Hydraulic System
Pump Type
Variable axial-piston
Relief Valve Pressure
3770psi
Pump Flow Capacity
68gal/min
Standard Blade
Width
14.8ft in
Height
51in
Capacity
7.9yd3
Cutting Depth
24in
