John Deere 850J WH Crawler Tractor

Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Units

Dimensions

Dimensions

A

Length W/ Blade

17.67ft in

B

Width Over Tracks

9.17ft in

C

Height To Top Of Cab

10.42ft in

D

Length Of Track On Ground

9.09ft in

E

Ground Clearance

16.11ft in

Undercarriage

G

Track Gauge

6.67ft in

H

Standard Shoe Size

30in

Number Of Track Rollers Per Side

7

Ground Pressure

6.11psi

Number Of Shoes Per Side

40

Ground Contact Area

7758in2

Track Pitch

8in


Specifications

Engine

Number Of Cylinders

6

Engine Make

2240

Engine Model

6090HT

Net Power

185hp

Power Measured @

1800rpm

Max Torque

611lb ft

Displacement

550cu in

Torque Measured @

1500rpm

Aspiration

Turbocharged with Aftercooler

Operational

Operating Weight

44665lb

Fuel Capacity

98gal

Cooling System Fluid Capacity

9.2gal

Engine Oil Capacity

7gal

Hydraulic Fluid Capacity

27.9gal

Powertrain Fluid Capacity

27.9gal

Alternator Supplied Amperage

80amps

Transmission

Transmission Type

Hydrostatic with direct drive

Max Speed - Forward

6.3mph

Max Speed - Reverse

6.3mph

Hydraulic System

Pump Type

Piston

Relief Valve Pressure

3625psi

Pump Flow Capacity

46gal/min

Standard Blade

Width

11.7ft in

Height

6.5in

Capacity

14.6yd3

Cutting Depth

23.6in
