John Deere 850J LT Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
18.75ft in
B
Width Over Tracks
8.83ft in
C
Height To Top Of Cab
10.42ft in
D
Length Of Track On Ground
10.78ft in
E
Ground Clearance
1.35ft in
Undercarriage
G
Track Gauge
6.83ft in
H
Standard Shoe Size
24in
Number Of Track Rollers Per Side
8
Ground Pressure
6.87psi
Number Of Shoes Per Side
45
Ground Contact Area
6206in2
Track Pitch
8in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6090HT
Gross Power
192hp
Net Power
185hp
Power Measured @
1800rpm
Max Torque
611lb ft
Displacement
550cu in
Torque Measured @
1500rpm
Aspiration
Turbocharger and aftercooler
Operational
Operating Weight
42708lb
Fuel Capacity
98gal
Cooling System Fluid Capacity
9.2gal
Engine Oil Capacity
7.1gal
Hydraulic Fluid Capacity
27.9gal
Powertrain Fluid Capacity
27.9gal
Final Drives Fluid Capacity
4.4gal
Operating Voltage
24V
Alternator Supplied Amperage
80amps
Transmission
Transmission Type
Hydrostatic
Max Speed - Forward
6.3mph
Max Speed - Reverse
6.3mph
Hydraulic System
Pump Type
Piston
Relief Valve Pressure
3625psi
Pump Flow Capacity
46gal/min
Standard Blade
Width
12.2ft in
Height
48.4in
Capacity
5.2yd3
Blade Angle (Both Directions)
23.8degrees
Cutting Depth
27.7in
