John Deere 8230 200 PTO hp MFWD Tractor

MFWD Tractor
MFWD Tractor
MFWD Tractor
MFWD Tractor
MFWD Tractor
MFWD Tractor
MODEL.UNITS

Dimensions

Dimensions

D

Wheelbase

10.01ft in


Specifications

Engine

Number Of Cylinders

6

Engine Make

2240

Gross Power

245hp

Pto Power

203.7hp

Power Measured @

2100rpm

Max Torque

740lb ft

Torque Measured @

1502rpm

Displacement

549.3cu in

Aspiration

turbocharged, air-to-air aftercooled

Operational

Fuel Capacity

180gal

3 Point Hitch Lift Capacity @ 24 Inches

12401.1lb

Turning Radius

18.7ft in

Tire Size Front - 2wd / 4wd

420/90R30

Rear Tires Size 2wd/4wd

480/80R46

Transmission

Transmission Type

Powershift

Number Of Forward Gears

16

Number Of Reverse Gears

4

Hydraulic System

Relief Valve Setting

2990psi

Pump Flow Capacity

44gal/min

Number Of Remote Control Valves

3
