John Deere 772GP Motor Grader
Units
Dimensions
Dimensions
A
Overall Length
29.17ft in
D
Wheelbase
20.21ft in
H
Blade Base
8.86ft in
Height To Top Of Isomount Cab
10.44ft in
Specifications
Engine
Engine Make
2240
Engine Model
PowerTech™ PSS
Displacement
415cu in
Operational
Hydraulic System Fluid Capacity
16gal
Oil System Fluid Capacity
8.4gal
Fuel Capacity
110.1gal
Cooling System Fluid Capacity
13.5gal
Transmission Fluid Capacity
7.6gal
Circle Gearbox Fluid Capacity
1.6gal
Steering
Turning Radius
23.7ft in
Transmission
Number Of Gears - Forward
8
Number Of Gears - Reverse
8
Front Axle
Wheel Lean
20degrees
Oscillation - Total
32degrees
Ground Clearance
2ft in
Moldboard
Moldboard Height
24.1in
Moldboard Thickness
0.9in
Hydraulic System
Pump Type
Closed-center, pressure-compensated load-sensing (PCLS), variable-displacement piston pump
Pump Flow
56.1gal/min
Relief Valve Pressure
2750.1psi
Circle
Diameter
60in
Rotation
360degrees
Shift Left
31in
Shift Right
31in
