John Deere 7520 MFWD Tractor

John Deere 7520 MFWD Tractor Specs front
John Deere 7520 MFWD Tractor Specs front
John Deere 7520 MFWD Tractor Specs side
John Deere 7520 MFWD Tractor Specs side
John Deere 7520 MFWD Tractor Specs back
John Deere 7520 MFWD Tractor Specs back
Units

Dimensions

Dimensions

D

Wheelbase

8.7 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Gross Power

150 hp

PTO Power

125.8 hp

Power Measured @

2100 rpm

Max Torque

454 lb ft

Torque Measured @

1503 rpm

Displacement

415

Aspiration

turbocharged

Operational

Operating Weight

13838.5 lb

Fuel Capacity

66.1 gal

3 Point Hitch Lift Capacity @ 24 inches

8959.6 lb

Turning Radius

15.1 ft in

Transmission

Transmission Type

PowerQuad Plus

Number of Forward Gears

16

Number of Reverse Gears

16

Hydraulic System

Relief Valve Setting

2900

Pump Flow Capacity

26.7 gal/min

Number of Remote Control Valves

2-4

Dimensions

Wheelbase

8.7 ft in


Compare similar models

Manufacturer / Model

Gross Power

Operating Weight

3 Point Hitch Lift Capacity @ 24 inches

Gross Power

135 hp

Operating Weight

13172.7 lb

3 Point Hitch Lift Capacity @ 24 inches

8959.6 lb

Gross Power

166 hp

Operating Weight

14594.7 lb

3 Point Hitch Lift Capacity @ 24 inches

10600 lb

Gross Power

125 hp

Operating Weight

13172.7 lb

3 Point Hitch Lift Capacity @ 24 inches

7449.5 lb
