John Deere 710B Loader Backhoe

Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Units

Dimensions

Backhoe

J

Load Height - Std

13.16 ft in

K

Reach From Swivel - Std

22.64 ft in

L

Dig Depth - Std

17.92 ft in

Dimensions

A

Transport Length

25.67 ft in

B

Transport Width

7.67 ft in

C

Transport Height

13.75 ft in

D

Wheelbase

7.88 ft in

E

Ground Clearance

1.17 ft in

Loader

G

Clearance at Max Dump Height

8.93 ft in

H

Reach at Max Dump Height

3.01 ft in

I

Dig Depth

3.94 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Engine Model

300 Series

Net Power

100 hp

Power Measured @

2200 rpm

Torque Measured @

1300 rpm

Net Max Torque

290 lb ft

Aspiration

Turbocharged

Displacement

329 cu in

Operational

Operating Weight 2wd

21803.8 lb

Fuel Capacity

33 gal

Hydraulic System Fluid Capacity

20 gal

Cooling System Fluid Capacity

6.9 gal

Transmission Fluid Capacity

20 gal

Front Axle Fluid Capacity

1.8 gal

Rear Axle Fluid Capacity

4.5 gal

Tire Size Front - 2wd / 4wd

14.5/75-16.1

Rear Tires Size 2wd/4wd

21L-24

Operating Voltage

12 V

Alternator Supplied Amperage

35 amps

Transmission

Transmission Type

Powershift

Number of Forward Gears

8

Number of Reverse Gears

4

Max Speed - Forward

19.5 mph

Max Speed Reverse

6.4 mph

Backhoe

Dig Depth - Std

18 ft in

Dig Depth - Ext

22.7 ft in

Reach From Swivel - Std

22.7 ft in

Reach From Swivel - Ext

27.1 ft in

Load Height - Std

13.2 ft in

Load Height - Ext

15.1 ft in

Loader

Bucket Capacity

1.6 yd3

Bucket Width

92.2 in

Lift Capacity at Full Height

6900 lb

Clearance at Max Dump Height

9 ft in

Reach at Max Dump Height

3.1 ft in

Dig Depth

4 in

Hydraulic

Pump Type

Close-Center

Pump Flow Capacity

47 gal/min

Relief Valve Pressure

3000 psi

Dimensions

Transport Length

25.7 ft in

Transport Width

7.7 ft in

Transport Height

13.8 ft in

Wheelbase

7.9 ft in

Ground Clearance

1.2 ft in
