John Deere 624H Integrated Tool Carrier
Units
Dimensions
Dimensions
A
Length W/ Bucket On Ground
24.97ft in
B
Width Over Tires
8.31ft in
C
Height To Top Of Cab
10.83ft in
D
Wheelbase
9.95ft in
E
Ground Clearance
1.34ft in
F
Hinge Pin Max Height
13ft in
G
Dump Clearance At Max Lift
9.38ft in
K
Max Lift Height
12.25ft in
I
Fork Tine Length
4.01ft in
L
Hook Height At Max Lift - Standard
18.96ft in
M
Hook Height At Max Lift - Extended
23.48ft in
N
Hook Reach At Max Lift - Standard
6.6ft in
O
Hook Reach At Max Lift - Extended
10.92ft in
Length With Out Forks On Ground
26.07ft in
Reach At Max Height And Dump
3.41ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6068H
Gross Power
160hp
Net Power
172hp
Power Measured @
2200rpm
Max Torque
575lb ft
Torque Measured @
1400rpm
Displacement
414cu in
Aspiration
Turbocharger with Aftercooler
Operational
Operating Weight
29894lb
Fuel Capacity
70gal
Cooling System Fluid Capacity
5.9gal
Engine Oil Capacity
5.3gal
Transmission Fluid Capacity
7.2gal
Front Diff Fluid Capacity
7.4gal
Rear Diff Fluid Capacity
5.3gal
Hydraulic System Fluid Capacity
31gal
Turning Radius
17.1ft in
Operating Voltage
24V
Alternator Supplied Amperage
55amps
Rear Axle Oscillation
26degrees
Static Tipping Load - Bucket
23647lb
Static Tipping Load - Forks
14740lb
Static Tipping Load - Material Handler
11292lb
Tire Size
17.5-25
Transmission
Transmission Type
Power Shift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed Forward
24.5mph
Max Speed Reverse
14.9mph
Hydraulic System
Pump Type
Piston Pump
Relief Valve Setting
3600psi
Pump Flow Capacity
55gal/min
Raise Time
5.8sec
Dump Time
1.4sec
Lower Time
3sec
Bucket
Breakout Force
27711lb
Bucket Capacity - Heaped
3.5yd3
Bucket Capacity - Struck
3yd3
