JCB 436HT High Lift Integrated Tool Carrier

Integrated Tool Carrier
Integrated Tool Carrier
Integrated Tool Carrier
Integrated Tool Carrier
Integrated Tool Carrier
Integrated Tool Carrier
Integrated Tool Carrier
Integrated Tool Carrier
Units

Dimensions

Dimensions

A

Length W/ Bucket On Ground

23.9ft in

B

Width Over Tires

8.53ft in

C

Height To Top Of Cab

10.95ft in

D

Wheelbase

9.85ft in

E

Ground Clearance

1.51ft in

F

Hinge Pin Max Height

15.26ft in

G

Dump Clearance At Max Lift

11.91ft in

K

Max Lift Height

14.71ft in

I

Fork Tine Length

4.01ft in

Reach At Max Height And Dump

3.43ft in


Specifications

Engine

Number Of Cylinders

6

Engine Make

2347

Engine Model

BTAA 5.9C

Gross Power

177hp

Net Power

165hp

Power Measured @

2200rpm

Max Torque

580lb ft

Torque Measured @

1300rpm

Displacement

360.1cu in

Aspiration

Turbocharged

Operational

Operating Weight

33892lb

Fuel Capacity

61gal

Cooling System Fluid Capacity

9gal

Engine Oil Capacity

3.7gal

Transmission Fluid Capacity

8.5gal

Front Diff Fluid Capacity

10.3gal

Rear Diff Fluid Capacity

10.3gal

Hydraulic System Fluid Capacity

55gal

Turning Radius

21.8ft in

Operating Voltage

24V

Alternator Supplied Amperage

70amps

Rear Axle Oscillation

21degrees

Static Tipping Load - Bucket

20426lb

Static Tipping Load - Forks

15147lb

Tire Size

20.5R25 XHA (L3)

Transmission

Transmission Type

Smooth shift powershift

Number Of Forward Gears

4

Number Of Reverse Gears

3

Max Speed Forward

23.5mph

Max Speed Reverse

16.8mph

Hydraulic System

Pump Type

Twin variable displacement piston pumps

Relief Valve Setting

3625psi

Pump Flow Capacity

69.8gal/min

Raise Time

5.9sec

Dump Time

1sec

Lower Time

3.4sec

Bucket

Breakout Force

33047lb

Bucket Capacity - Heaped

3.1yd3

Bucket Capacity - Struck

2.7yd3
