John Deere 624E w/ Coupler Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
9.67ft in
Bucket Capacity - Heaped
2.25yd3
Bucket Capacity - Struck
1.88yd3
Bucket Width
8.37ft in
Breakout Force
30768lb
Dimensions
A
Length With Bucket On Ground
24.09ft in
B
Width Over Tires
8.17ft in
C
Height To Top Of Cab
10.73ft in
D
Wheelbase
9.95ft in
F
Hinge Pin - Max Height
12.77ft in
H
Reach At Max Lift And Dump
2.92ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6414T
Net Power
135hp
Gross Power
141hp
Power Measured @
2200rpm
Max Torque
420lb ft
Displacement
414cu in
Torque Measured @
1300rpm
Aspiration
Turbocharged
Operational
Operating Weight
27661lb
Fuel Capacity
55gal
Hydraulic System Fluid Capacity
27gal
Engine Oil Fluid Capacity
5.1gal
Cooling System Fluid Capacity
6.7gal
Transmission Fluid Capacity
2.7gal
Front Axle/Diff Fluid Capacity
6.1gal
Rear Axle/Diff Fluid Capacity
4.3gal
Static Tipping Weight
20915lb
Turning Radius
16.8ft in
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Rear Axle Oscillation
26degrees
Tire Size
17.5-25
Transmission
Transmission Type
Power Shift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed - Forward
25.4mph
Max Speed - Reverse
16mph
Hydraulic System
Relief Valve Setting
2800psi
Pump Flow Capacity
57gal/min
Raise Time
5.8sec
Dump Time
1.7sec
Lower Time
3.5sec
Pump Type
Gear
