John Deere 544G Integrated Tool Carrier

John Deere 544G Integrated Tool Carrier Specs front
John Deere 544G Integrated Tool Carrier Specs front
John Deere 544G Integrated Tool Carrier Specs extended_1
John Deere 544G Integrated Tool Carrier Specs extended_1
John Deere 544G Integrated Tool Carrier Specs extended_2
John Deere 544G Integrated Tool Carrier Specs extended_2
John Deere 544G Integrated Tool Carrier Specs extended_3
John Deere 544G Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

23.17 ft in

B

Width Over Tires

7.94 ft in

C

Height to Top of Cab

10.41 ft in

D

Wheelbase

9.52 ft in

E

Ground Clearance

1.23 ft in

F

Hinge Pin Max Height

12.21 ft in

G

Dump Clearance at Max Lift

8.92 ft in

I

Fork Tine Length

4 ft in

K

Max Lift Height

11.4 ft in

L

Hook Height at Max Lift - standard

17.83 ft in

M

Hook Height at Max Lift - extended

22.1 ft in

N

Hook Reach at Max Lift - standard

6.75 ft in

O

Hook Reach at Max Lift - extended

11.31 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Engine Model

6059T

Gross Power

125 hp

Net Power

120 hp

Power Measured @

2200 rpm

Max Torque

388 lb ft

Torque Measured @

1400 rpm

Displacement

359

Aspiration

Turbocharged

Operational

Operating Weight

24092 lb

Fuel Capacity

57.6 gal

Cooling System Fluid Capacity

6.4 gal

Engine Oil Capacity

5.1 gal

Transmission Fluid Capacity

2.6 gal

Front Diff Fluid Capacity

5.1 gal

Rear Diff Fluid Capacity

5.1 gal

Hydraulic System Fluid Capacity

20.1 gal

Turning Radius

16.3 ft in

Operating Voltage

12 V

Alternator Supplied Amperage

95 amps

Rear Axle Oscillation

22 degrees

Static Tipping Load - Bucket

18453 lb

Static Tipping Load - Forks

13665 lb

Static Tipping Load - Material Handler

8945 lb

Tire Size

17.5-25

Transmission

Transmission Type

Power shift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed Forward

23.8 mph

Max Speed Reverse

16.9 mph

Hydraulic System

Pump Type

Gear type

Relief Valve Setting

2750

Pump Flow Capacity

46.3 gal/min

Raise Time

5.8 sec

Dump Time

1.4 sec

Lower Time

3.2 sec

Bucket

Breakout Force

20342 lb

Bucket Capacity - heaped

2.7 yd3

Bucket Capacity - struck

2.3 yd3

Dimensions

Width Over Tires

8 ft in

Height to Top of Cab

10.5 ft in

Wheelbase

9.6 ft in

Ground Clearance

1.3 ft in

Hinge Pin Max Height

12.3 ft in

Length w/ Bucket on Ground

23.2 ft in

Dump Clearance at Max Lift

9 ft in

Reach at Max Height and Dump

3.5 ft in

Fork Tine Length

4 ft in

Length with out Forks on Ground

25.4 ft in

Max Lift Height

11.4 ft in

Hook Height at Max Lift - Standard

17.9 ft in

Hook Height at Max Lift - Extended

22.1 ft in

Hook Reach at Max Lift - Standard

6.8 ft in

Hook Reach at Max Lift - Extended

11.4 ft in
