Caterpillar 924G Integrated Tool Carrier

Caterpillar 924G Integrated Tool Carrier Specs front
Caterpillar 924G Integrated Tool Carrier Specs front
Caterpillar 924G Integrated Tool Carrier Specs extended_1
Caterpillar 924G Integrated Tool Carrier Specs extended_1
Caterpillar 924G Integrated Tool Carrier Specs extended_2
Caterpillar 924G Integrated Tool Carrier Specs extended_2
Caterpillar 924G Integrated Tool Carrier Specs extended_3
Caterpillar 924G Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

23.52 ft in

B

Width Over Tires

7.73 ft in

C

Height to Top of Cab

10.59 ft in

D

Wheelbase

9.19 ft in

E

Ground Clearance

1.44 ft in

F

Hinge Pin Max Height

12.74 ft in

G

Dump Clearance at Max Lift

9.28 ft in

I

Fork Tine Length

3.94 ft in

K

Max Lift Height

5.88 ft in

L

Hook Height at Max Lift - standard

20.73 ft in

M

Hook Height at Max Lift - extended

23.62 ft in

N

Hook Reach at Max Lift - standard

6.18 ft in

O

Hook Reach at Max Lift - extended

7.73 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3056E DIT ATAAC

Gross Power

138.2 hp

Net Power

130.1 hp

Displacement

366.2

Operational

Operating Weight

25000.5 lb

Fuel Capacity

59.5 gal

Cooling System Fluid Capacity

10.6 gal

Engine Oil Capacity

5.3 gal

Transmission Fluid Capacity

6.1 gal

Front Diff Fluid Capacity

5.6 gal

Rear Diff Fluid Capacity

5.6 gal

Hydraulic System Fluid Capacity

33.1 gal

Turning Radius

16.7 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

80 amps

Rear Axle Oscillation

12 degrees

Static Tipping Load - Bucket

18267.6 lb

Static Tipping Load - Forks

13688.6 lb

Static Tipping Load - Material Handler

7872.8 lb

Tire Size

17.5-25

Transmission

Transmission Type

countershaft

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed Forward

24.3 mph

Max Speed Reverse

13.7 mph

Hydraulic System

Pump Type

variable displacement axial piston implement pump

Relief Valve Setting

3756.5

Pump Flow Capacity

304.4 gal/min

Raise Time

5.1 sec

Dump Time

1.4 sec

Lower Time

2.4 sec

Bucket

Breakout Force

21806.5 lb

Bucket Capacity - heaped

2.4 yd3

Bucket Capacity - struck

2 yd3

Dimensions

Width Over Tires

7.8 ft in

Height to Top of Cab

10.6 ft in

Wheelbase

9.2 ft in

Ground Clearance

1.5 ft in

Hinge Pin Max Height

12.8 ft in

Length w/ Bucket on Ground

23.6 ft in

Dump Clearance at Max Lift

9.3 ft in

Reach at Max Height and Dump

3.3 ft in

Fork Tine Length

4 ft in

Length with out Forks on Ground

25 ft in

Max Lift Height

5.9 ft in

Hook Height at Max Lift - Standard

20.8 ft in

Hook Height at Max Lift - Extended

23.7 ft in

Hook Reach at Max Lift - Standard

6.2 ft in

Hook Reach at Max Lift - Extended

7.8 ft in
