John Deere 544B Wheel Loader

Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Units

Dimensions

Bucket

G

Dump Clearance At Max Raise

8.83ft in

Breakout Force

17885lb

Bucket Capacity - Heaped

1.76yd3

Bucket Capacity - Struck

1.43yd3

Bucket Width

7.68ft in

Dimensions

E

Ground Clearance

1.3ft in

A

Length With Bucket On Ground

19.25ft in

C

Height To Top Of Cab

10.08ft in

D

Wheelbase

6.7ft in

F

Hinge Pin - Max Height

11.23ft in

H

Reach At Max Lift And Dump

2.9ft in


Specifications

Engine

Number Of Cylinders

6

Engine Make

2240

Net Power

105hp

Gross Power

115hp

Power Measured @

2200rpm

Max Torque

325lb ft

Displacement

414cu in

Torque Measured @

1400rpm

Aspiration

Turbocharged

Operational

Operating Weight

21775lb

Fuel Capacity

40gal

Hydraulic System Fluid Capacity

12gal

Engine Oil Fluid Capacity

5gal

Cooling System Fluid Capacity

8.1gal

Transmission Fluid Capacity

9.8gal

Front Axle/Diff Fluid Capacity

6gal

Rear Axle/Diff Fluid Capacity

6.3gal

Static Tipping Weight

16395lb

Turning Radius

13.9ft in

Operating Voltage

12V

Rear Axle Oscillation

22degrees

Tire Size

17.5- 25

Transmission

Transmission Type

Powershift planetary

Number Of Forward Gears

4

Number Of Reverse Gears

2

Max Speed - Forward

25mph

Max Speed - Reverse

10mph

Hydraulic System

Relief Valve Setting

2250psi

Pump Flow Capacity

44.5gal/min

Pump Type

Engine driven vane
