John Deere 450G LT Crawler Tractor

John Deere 450G LT Crawler Tractor Specs front
John Deere 450G LT Crawler Tractor Specs front
John Deere 450G LT Crawler Tractor Specs side
John Deere 450G LT Crawler Tractor Specs side
John Deere 450G LT Crawler Tractor Specs back
John Deere 450G LT Crawler Tractor Specs back
Units

Dimensions

Dimensions

B

Width Over Tracks

6.09 ft in

C

Height to Top of Cab

8.99 ft in

D

Length of Track on Ground

6.34 ft in

E

Ground Clearance

1.19 ft in

F

Length w/o Blade

12.86 ft in

Undercarriage

H

Standard Shoe Size

16 in


Specifications

Engine

Engine Make

2240

Engine Model

e 4045D

Gross Power

73 hp

Net Power

70 hp

Displacement

276 cu in

Aspiration

Naturally aspirated

Operational

Operating Weight

15732 lb

Fuel Capacity

41 gal

Cooling System Fluid Capacity

4.5 gal

Engine Oil Capacity

2.3 gal

Hydraulic Fluid Capacity

14.6 gal

Powertrain Fluid Capacity

27 gal

Final Drives Fluid Capacity

1.8 gal

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Transmission

Transmission Type

Full power shift, Dura-Shift with direct drive

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

5.6 mph

Max Speed - Reverse

6.1 mph

Undercarriage

Ground Pressure

6.5 psi

Ground Contact Area

2432 in2

Standard Shoe Size

16 in

Number of Shoes per Side

37

Number of Track Rollers per Side

5

Track Pitch

6.3 in

Hydraulic System

Pump type

Gear

Relief Valve Pressure

2750 psi

Pump Flow Capacity

17 gal/min

Standard Blade

Width

8.1 ft in

Height

32.6 in

Capacity

2 yd3

Blade Angle (both directions)

25 degrees

Cutting Depth

19.9 in

Dimensions

Length w/o Blade

12.9 ft in

Width Over Tracks

6.1 ft in

Height to Top of Cab

9 ft in

Length of Track on Ground

6.4 ft in

Ground Clearance

1.2 ft in
