John Deere 450G LPG Crawler Tractor

John Deere 450G LPG Crawler Tractor Specs front
John Deere 450G LPG Crawler Tractor Specs front
John Deere 450G LPG Crawler Tractor Specs side
John Deere 450G LPG Crawler Tractor Specs side
John Deere 450G LPG Crawler Tractor Specs back
John Deere 450G LPG Crawler Tractor Specs back
Units

Dimensions

Dimensions

B

Width Over Tracks

7.75 ft in

C

Height to Top of Cab

8.99 ft in

D

Length of Track on Ground

7.09 ft in

E

Ground Clearance

1.19 ft in

Undercarriage

H

Standard Shoe Size

24 in


Specifications

Engine

Engine Make

2240

Engine Model

e 4045T

Gross Power

73 hp

Net Power

70 hp

Displacement

276 cu in

Aspiration

Altitude compensating turbocharged

Operational

Operating Weight

17432 lb

Fuel Capacity

41 gal

Cooling System Fluid Capacity

4.5 gal

Engine Oil Capacity

2.3 gal

Hydraulic Fluid Capacity

14.6 gal

Powertrain Fluid Capacity

27 gal

Final Drives Fluid Capacity

1.8 gal

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Transmission

Transmission Type

Full power shift, Dura-Shift with torque converter

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

6 mph

Max Speed - Reverse

6 mph

Undercarriage

Ground Pressure

4.3 psi

Ground Contact Area

4099 in2

Standard Shoe Size

24 in

Number of Shoes per Side

40

Number of Track Rollers per Side

6

Track Pitch

6.3 in

Hydraulic System

Pump type

Gear

Relief Valve Pressure

2750 psi

Pump Flow Capacity

17 gal/min

Standard Blade

Width

8.1 ft in

Height

32.6 in

Capacity

2 yd3

Blade Angle (both directions)

25 degrees

Cutting Depth

19.9 in

Dimensions

Width Over Tracks

7.8 ft in

Height to Top of Cab

9 ft in

Length of Track on Ground

7.1 ft in

Ground Clearance

1.2 ft in
