John Deere 415B Loader Backhoe

Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
Loader Backhoe
MODEL.UNITS

Dimensions

Dimensions

Height To Top Of Suspended Cab

8.67ft in


Specifications

Engine

Number Of Cylinders

4

Engine Make

2240

Engine Model

300 Series

Net Power

68hp

Power Measured @

2500rpm

Torque Measured @

1400rpm

Net Max Torque

170lb ft

Aspiration

Naturally aspirated

Displacement

239cu in

Operational

Fuel Capacity

23gal

Max Weight

16000lb

Hydraulic System Fluid Capacity

19gal

Oil System Fluid Capacity

2.3gal

Cooling System Fluid Capacity

4.3gal

Transmission Fluid Capacity

3.5gal

Turning Radius

11.7ft in

Tire Size Front - 2wd / 4wd

11L-16 F3

Rear Tires Size 2wd/4wd

19.5L-24 R4

Operating Voltage

12V

Alternator Supplied Amperage

65amps

Transmission

Transmission Type

4-speed with first and second collar shift, third and fourth synchronized with hydraulic server

Number Of Forward Gears

4

Number Of Reverse Gears

4

Hydraulic

Pump Type

Close-center

Pump Flow Capacity

23gal/min

Relief Valve Pressure

3200psi
