John Deere 370E Articulated Dump Truck

John Deere 370E Articulated Dump Truck Specs front
John Deere 370E Articulated Dump Truck Specs front
John Deere 370E Articulated Dump Truck Specs side
John Deere 370E Articulated Dump Truck Specs side
John Deere 370E Articulated Dump Truck Specs back
John Deere 370E Articulated Dump Truck Specs back
Units

Dimensions

Dimensions

A

Overall Length

35.47 ft in


Specifications

Driveline

Engine Model

PowerTech 6135

Displacement

823.9 cu in

Engine Manufacturer

John Deere

Emission Rating

Tier 4

Rated Speed

1900 rpm

Parking Brake Type

Disc - Transmission

Transmission Type

Countershaft

Differential lock

F: 100 / R: 100

Service Brake Actuation

Hydraulic

Tire size - Standard

23.5 R25

Rear Suspension - Type

Pivoting Walking Beam

Final drive

Planetary - Outboard

Retarder - Type

Hydraulic - Transmission

Transmission Manufacturer

ZF

Secondary Steering Type

Ground Driven Pump

Rear Suspension

Rubber Suspension Blocks

Front Suspension - Type

A-Frame

Front Suspension

Nitrogen/Oil-Filled Struts - Auto Levelling

Steering Type

Articulated

Capacities

Fuel Tank - diesel

160.9 gal

Struck Capacity

21.4 yd3

Heaped Capacity

26.9 yd3

Description

Fleet Management

Yes

Steering wheel adjustment

Fully Adjustable

Telematics Available

Yes

Air Conditioner

Yes

Performance

Gears - Forward / Reverse

8F - 4R

Weights

Payload

74139.3 lb

Gross Weight

142002 lb

Net Weight

67862.7 lb

Dimensions

Max height

12.5 ft in

Articulation Angle

45

Hoist - Type

Twin, 1-Stage

Approach Angle

24

Turns lock to lock

4.2

Power Down

Yes

Turning Radius - Inside

15.2 ft in

Width Over Tires

11.3 ft in

Overall Length

35.5 ft in

Turning Radius Outside Tires

29.2 ft in
