John Deere 3554 Road Builder Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
36.46ft in
I
Max Cutting Height
34.59ft in
K
Max Reach Along Ground
36.42ft in
L
Max Vertical Wall Digging Depth
21ft in
M
Max Digging Depth
23.1ft in
Boom/Stick Option (Hex) 1
standard arm 10\'6\" (2960mm)
Dimensions
E
Ground Clearance
2.34ft in
G
Height To Top Of Cab
12.57ft in
B
Width To Outside Of Tracks
11.16ft in
D
Length Of Track On Ground
13.26ft in
H
Tail Swing Radius
11.75ft in
Undercarriage
F
Track Gauge
8.83ft in
N
Shoe Size
27.96in
Max Travel Speed
3.42mph
Drawbar Pull
56074lb
Number Of Carrier Rollers Per Side
2
Number Of Track Rollers Per Side
9
Ground Pressure
9.1psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6081H
Net Power
245.5hp
Power Measured @
2000rpm
Max Torque
940.4lb ft
Displacement
494cu in
Aspiration
turbocharged
Torque Measured @
1100rpm
Operational
Operating Weight
85700.3lb
Fuel Capacity
269gal
Cooling System Fluid Capacity
14.7gal
Hydraulic System Fluid Capacity
85.1gal
Engine Oil Capacity
8gal
Operating Voltage
24V
Swing Drive Fluid Capacity
3.7gal
Alternator Supplied Amperage
45amps
Hydraulic System Relief Valve Pressure
5050psi
Hydraulic Pump Flow Capacity
154.3gal/min
Swing Mechanism
Swing Speed
11.6rpm
Swing Torque
82862.9lb ft
