John Deere 244J Wheel Loader

John Deere 244J Wheel Loader Specs front
John Deere 244J Wheel Loader Specs front
John Deere 244J Wheel Loader Specs side
John Deere 244J Wheel Loader Specs side
John Deere 244J Wheel Loader Specs back
John Deere 244J Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

8.33 ft in

Dimensions

A

Length with Bucket on Ground

17.33 ft in

B

Width Over Tires

7 ft in

C

Height to Top of Cab

8.92 ft in

D

Wheelbase

7 ft in

E

Ground Clearance

1 ft in

F

Hinge Pin - Max Height

10.5 ft in

H

Reach at Max Lift and Dump

2.68 ft in


Specifications

Engine

Engine Make

2240

Engine Model

e 4024T

Net Power

59 hp

Gross Power

64 hp

Displacement

149 cu in

Max Torque

163

Torque Rise

47.3 %

Aspiration

Turbocharged

Operational

Operating Weight

11552 lb

Fuel Capacity

22 gal

Hydraulic System Fluid Capacity

16 gal

Engine Oil Fluid Capacity

9 gal

Cooling System Fluid Capacity

10.6 gal

Front Axle/Diff Fluid Capacity

4.2 gal

Rear Axle/Diff Fluid Capacity

4.3 gal

Static Tipping Weight

8457 lb

Turning Radius

11.5 ft in

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Rear Axle Oscillation

20 degrees

Tire Size

365/70R18

Transmission

Transmission Type

Hydrostatic

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed - Forward

18.6 mph

Max Speed - Reverse

18.6 mph

Hydraulic System

Pump Type

Gear

Relief Valve Setting

3190

Pump Flow Capacity

17 gal/min

Raise Time

4.9 sec

Dump Time

1.4 sec

Lower Time

4 sec

Bucket

Breakout Force

10792 lb

Dump Clearance at Max Raise

8.4 ft in

Bucket Width

74.8 ft in

Bucket Capacity - heaped

1 yd3

Bucket Capacity - struck

0.9 yd3

Dimensions

Length with Bucket on Ground

17.4 ft in

Width Over Tires

7 ft in

Height to Top of Cab

9 ft in

Ground Clearance

1 ft in

Wheelbase

7 ft in

Hinge Pin - Max Height

10.5 ft in

Reach at Max Lift and Dump

2.7 ft in
