Caterpillar 906H2 Wheel Loader

Caterpillar 906H2 Wheel Loader Specs front
Caterpillar 906H2 Wheel Loader Specs front
Caterpillar 906H2 Wheel Loader Specs side
Caterpillar 906H2 Wheel Loader Specs side
Caterpillar 906H2 Wheel Loader Specs back
Caterpillar 906H2 Wheel Loader Specs back
Units

Dimensions

Dimensions

A

Length with Bucket on Ground

18.33 ft in

D

Wheelbase

7.12 ft in

E

Ground Clearance

0.99 ft in

F

Hinge Pin - Max Height

10.6 ft in

H

Reach at Max Lift and Dump

4.16 ft in


Specifications

Engine

Engine Make

2236

Engine Model

C3.3B DIT

Net Power

68 hp

Gross Power

74 hp

Operational

Operating Weight

4553 lb

Fuel Capacity

13.7 gal

Hydraulic System Fluid Capacity

25 gal

Engine Oil Fluid Capacity

2.7 gal

Cooling System Fluid Capacity

6.3 gal

Transmission

Number of Forward Gears

3

Max Speed - Forward

21.7 mph

Hydraulic System

Pump Type

PISTON

Relief Valve Setting

3400

Pump Flow Capacity

22 gal/min

Raise Time

5 sec

Dump Time

2 sec

Lower Time

4 sec

Dimensions

Length with Bucket on Ground

18.4 ft in

Ground Clearance

1 ft in

Wheelbase

7.2 ft in

Hinge Pin - Max Height

10.6 ft in

Reach at Max Lift and Dump

4.2 ft in
