JCB JS180LC TAB Hydraulic Excavator
Dimensions
Boom/Stick Option (Hex) 1
Max Cutting Height
33.55ft in
Max Loading Height
26.17ft in
Max Reach Along Ground
28.39ft in
Max Vertical Wall Digging Depth
145.2ft in
Max Digging Depth
17.64ft in
Boom/Stick Option (Hex) 1
T.A. boom 5350 mm with arm 2250 mm
Max Digging Reach On Ground
28.39ft in
Minimum Swing Radius
85.44in
Max Digging Reach
29.08ft in
Boom/Stick Option (Hex) 2
Max Cutting Height
34.95ft in
Max Loading Height
27.45ft in
Max Reach Along Ground
29.84ft in
Max Vertical Wall Digging Depth
15.49ft in
Max Digging Depth
19.06ft in
Max Digging Reach
30.39ft in
Max Digging Reach On Ground
29.84ft in
Minimum Swing Radius
87.68in
Boom/Stick Option (Hex) 2
T.A. boom 5350 mm with arm 2700 mm
Boom/Stick Option (Hex) 3
Max Cutting Height
35.44ft in
Max Loading Height
28.44ft in
Max Reach Along Ground
31.05ft in
Max Vertical Wall Digging Depth
17.17ft in
Max Digging Depth
20.12ft in
Minimum Swing Radius
101.86in
Max Digging Reach
31.47ft in
Max Digging Reach On Ground
21.21ft in
Boom/Stick Option (Hex) 3
T.A. boom 5350 mm with arm 2700 mm
Dimensions
Ground Clearance
1.6ft in
Height To Top Of Cab
9.8ft in
Width To Outside Of Tracks
9.19ft in
Length Of Track On Ground
11.06ft in
Tail Swing Radius
7.68ft in
Transport Height
124.49in
Transport Length
340.63in
Undercarriage Overall Length
13.69ft in
Removal Counterweight Clearance
3.52ft in
Undercarriage
Track Gauge
7.22ft in
Shoe Size
23.63in
Max Travel Speed
3.11mph
Number Of Carrier Rollers Per Side
2
Number Of Shoes Per Side
46
Number Of Track Rollers Per Side
7
Track Adjustment
Grease cylinder type
Ground Pressure
6.12psi
Specifications
Engine
Battery
2 x 12 volt
Number Of Cylinders
4
Engine Make
2353
Engine Model
JCB EcoMAX 444 TCA EU Stage IV, EPA Tier 4 Final compliant
Net Power
109hp
Power Measured @
2200rpm
Displacement
264.2cu in
Alternator
55amps
Capacities
Def Tank
14.3gal
Engine Oil
0.6gal
Engine Coolant
5.3gal
Operational
Operating Weight
42328.8lb
Fuel Capacity
66.9gal
Cooling System Fluid Capacity
4.4gal
Hydraulic System Fluid Capacity
37.6gal
Operating Voltage
24V
Engine Oil Capacity
3.5gal
Swing Drive Fluid Capacity
1.6gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4975psi
Hydraulic Pump Flow Capacity
73gal/min
Swing Mechanism
Swing Gear
Large diameter, internally toothed fully sealed grease bath lubricated
Swing Motor
Axial piston type
Swing Brake
Hydraulic braking plus automatic spring applied disc type parking brake
Swing Torque
2581.5lb ft
Swing Speed
10rpm
Buckets
Reference Bucket Capacity
1.2yd3
Minimum Bucket Capacity
0.5yd3
Maximum Bucket Capacity
1.2yd3
Hydraulic System
Power Boost
23.5psi
Maximum Flow -Servo Pump, Low Noise Gear Pump
5.5gal/min
Main Pump - Maximum Flow
86.7gal/min
Travel Circuit
23.5psi
Swing Circuit
19.3psi
Pilot Circuit
2.8psi
Control Valve
A combined ten spool control valve with auxiliary service spool as standard
Brakes
Park Brake
Disc type, spring applied, automatic hydraulic release
Service Brake
Hydraulic counter balance valve
Gradeability
70 %
