JCB JS131 LC Hydraulic Excavator
Dimensions
Dimensions
Ground Clearance
1.4ft in
Height To Top Of Cab
9.34ft in
Width To Outside Of Tracks
8.17ft in
Length Of Track On Ground
9.4ft in
Tail Swing Radius
7.01ft in
Track Gauge
6.53ft in
Counterweight Clearance
2.97ft in
Tailswing Radius
7.01ft in
Transport Height
112.88in
Transport Length
295.87in
Undercarriage Overall Length
11.83ft in
Undercarriage
Track Adjustment
Grease cylinder type.
Number Of Shoes Per Side
44
Specifications
Slew System
Slew Motor
Axial piston type
Slew Brake
Hydraulic braking plus automatic spring applied disc type parking brake
Slew Torque
36.2 KNm
Slew Speed
13.3rpm
Slew Gear
Large diameter, internally toothed fully sealed grease bath lubricated.
Engine
Air Filter Type
Dry
Starting System
24 V
Battery
2 x 12 V
Fuel Tank
58.2gal
Engine Model
JCB EcoMAX 444 TCA 55 EU Stage IIIB, EPA Tier 4 Final compliant
Engine Type
Water cooled, 4-stroke, 4-cylinder in-line, common rail injection, turbocharged fixed geometry intercooled diese
Net Power
74hp
Power Measured @
1800rpm
Displacement
268.6cu in
Alternator
55amps
Operational
Fuel Capacity
58.2gal
Cooling System Fluid Capacity
5.3gal
Hydraulic System Fluid Capacity
33.3gal
Engine Oil Capacity
3.7gal
Hydraulic System
Power Boost
4974.8psi
Main Pump - Maximum Flow
34.4gal/min
Maximum Flow -Servo Pump, Low Noise Gear Pump
5.3gal/min
Bucket
Multi Purpose Bucket Weight
630.6lb
Hydraulic System
Travel Circuit
4974.8psi
Swing Circuit
4046.6psi
Pilot Circuit
580.2psi
Control Valve
A combined four and five spool control valve with auxiliary service spool as standard
Bucket
Bucket Width
2ft in
Largest Bucket Capacity
0.5yd3
Brakes
Park Brake
Disc type, spring applied, automatic hydraulic release.
Master Brake
Planetary reduction, bolt-on sprockets
Service Brake
Hydraulic counter balance valve
Travel Speed
4.2mph
Gradeability
75
