JCB 531-70 AGRI Telescopic Forklift

JCB 531-70 AGRI Telescopic Forklift Specs front
JCB 531-70 AGRI Telescopic Forklift Specs front
JCB 531-70 AGRI Telescopic Forklift Specs side
JCB 531-70 AGRI Telescopic Forklift Specs side
JCB 531-70 AGRI Telescopic Forklift Specs extended
JCB 531-70 AGRI Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

16.38 ft in

B

Width Over Tires

7.68 ft in

C

Overall Height

8.17 ft in

D

Wheelbase

9.03 ft in

E

Ground Clearance

1.32 ft in

Lift

F

Max Lift Height

22.97 ft in

G

Max Forward Reach

12.14 ft in


Specifications

Electrical System

Battery capacity

220 Ah

Alternator

150 Ah

Voltage

12 V

Engine

Emissions level

Tier 4 Final / Stage IV

Number of Cylinders

4

Engine Make

2257

Engine Model

Agri

Gross Power

108.7 hp

Power Measured @

2200 rpm

Max Torque

380.6 lb ft

Torque Measured @

1500 rpm

Displacement

268.6 cu in

Bore

4.1 in

Stroke

5.2 in

Aspiration

Turbocharged cooled

Capacities

Coolant (Engine)

6.1 gal

Fuel Tank

38.6 gal

Hydraulic Tank

29.9 gal

Diesel exhaust fluid (DEF) tank

5.5 gal

Engine Oil

3.7 gal

Operational

Operating Weight

14990 lb

Operating Voltage

12 V

Alternator Supplied Amperage

65 amps

Tire Size

17.5LR24

Transmission

Lift capacity at full reach

2755.8 lb

Travel Speed

20.6 mph

Transmission Type

Powershift

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - forward

20.5 mph

Max Speed - reverse

20.5 mph

Hydraulic System

Retract

5 sec

Extend

6.7 sec

Bucket crowd

2.3 sec

Hydraulic

Pump Flow Capacity

50.5 gal/min

Relief Valve Pressure

3495 psi

Hydraulic System

Raise Time

4.5 sec

Dump Time

2.9 sec

Lower Time

5.7 sec

Lift

Max Lift Capacity

6834.4 lb

Max Lift Height

23 ft in

Max Load at Max Height

5000 lb

Max Forward Reach

12.2 ft in

Max Load at Max Reach

3000.5 lb

Dimensions

Dump angle

37.5 degrees

Weight

15917.4 lb

Length to Fork Face

16.4 ft in

Width Over Tires

7.7 ft in

Overall Height

8.2 ft in

Wheelbase

9.1 ft in

Ground Clearance

1.4 ft in

Turning Radius Outside Tires

12 ft in
