JCB 457 HT SHL Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
12.97ft in
Bucket Capacity - Heaped
3.67yd3
Bucket Capacity - Struck
2.9yd3
Bucket Width
9.31ft in
Breakout Force
39341.57lb
Dimensions
E
Ground Clearance
1.56ft in
A
Length With Bucket On Ground
31.01ft in
B
Width Over Tires
8.86ft in
C
Height To Top Of Cab
11.27ft in
D
Wheelbase
10.83ft in
F
Hinge Pin - Max Height
17.3ft in
H
Reach At Max Lift And Dump
4.33ft in
Specifications
Engine
Emission Tier Level
EPA 40 CFR 89 / Tier 4 Final EU 97/68/EC/STAGE IV
Number Of Cylinders
6
No. Of Valves
4
Engine Model
6R1000
Engine Type
MTU
Net Power
256hp
Air Cleaner
Intergrated pre-cleaner, scavenged
Gross Power
258hp
Power Measured @
1600rpm
Max Torque
1150 Nm
Displacement
469.9cu in
Torque Measured @
1600rpm
Aspiration
Turbo Charged
Fan Drive Type
Hydraulic
Operational
Def Tank Capacity
11.1gal
Full Turn Tipping Load
19861.5lb
Payload
9931.9lb
Operating Weight
47273.8lb
Fuel Capacity
79.3gal
Hydraulic System Fluid Capacity
35.7gal
Engine Oil Fluid Capacity
6.7gal
Cooling System Fluid Capacity
11.1gal
Transmission Fluid Capacity
10.9gal
Front Axle/Diff Fluid Capacity
9.3gal
Rear Axle/Diff Fluid Capacity
9.3gal
Turning Radius
23.4ft in
Operating Voltage
24V
Alternator Supplied Amperage
100amps
Rear Axle Oscillation
11.5degrees
Articulation Angle
40degrees
Transmission
Transmission Type
4 speed non-lock up converter ZF 4WG210
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed - Forward
22.5mph
Max Speed - Reverse
14.7mph
Hydraulic System
Max Operating Pressure
220 bar
Relief Valve Setting
3190psi
Pump Flow Capacity
40.5gal/min
Raise Time
5.8sec
Dump Time
1.2sec
Lower Time
4.1sec
Total Cycle
11.1sec
Pump Type
Variable displacement
