JCB 456HT High Lift Wheel Loader

JCB 456HT High Lift Wheel Loader Specs front
JCB 456HT High Lift Wheel Loader Specs front
JCB 456HT High Lift Wheel Loader Specs side
JCB 456HT High Lift Wheel Loader Specs side
JCB 456HT High Lift Wheel Loader Specs back
JCB 456HT High Lift Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

13.06 ft in

Dimensions

A

Length with Bucket on Ground

31.01 ft in

B

Width Over Tires

8.87 ft in

C

Height to Top of Cab

11.06 ft in

D

Wheelbase

6.89 ft in

E

Ground Clearance

1.55 ft in

F

Hinge Pin - Max Height

16.39 ft in

H

Reach at Max Lift and Dump

4.38 ft in


Specifications

Engine

Engine Model

QSC 8.3

Net Power

215 hp

Gross Power

207 hp

Displacement

8.3 cu in

Max Torque

675

Aspiration

Turbo charged

Operational

Operating Weight

47036 lb

Fuel Capacity

84 gal

Hydraulic System Fluid Capacity

57 gal

Engine Oil Fluid Capacity

5 gal

Cooling System Fluid Capacity

10.5 gal

Transmission Fluid Capacity

9 gal

Front Axle/Diff Fluid Capacity

18 gal

Rear Axle/Diff Fluid Capacity

13 gal

Static Tipping Weight

21363 lb

Turning Radius

10.5 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

70 amps

Rear Axle Oscillation

25 degrees

Tire Size

23.5R25 XHA (L3)

Transmission

Transmission Type

Smooth shift powershift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - Forward

23.4 mph

Max Speed - Reverse

15.3 mph

Hydraulic System

Pump Type

Twin variable displacement piston pump

Relief Valve Setting

3625

Pump Flow Capacity

43 gal/min

Raise Time

5.8 sec

Dump Time

1.2 sec

Lower Time

4.1 sec

Bucket

Dump Clearance at Max Raise

13.1 ft in

Bucket Width

9.4 ft in

Bucket Capacity - heaped

4.9 yd3

Bucket Capacity - struck

3.8 yd3

Dimensions

Length with Bucket on Ground

31.1 ft in

Width Over Tires

8.9 ft in

Height to Top of Cab

11.1 ft in

Ground Clearance

1.6 ft in

Wheelbase

6.9 ft in

Hinge Pin - Max Height

16.4 ft in

Reach at Max Lift and Dump

4.4 ft in
