JCB 446ZX Wheel Loader

JCB 446ZX Wheel Loader Specs front
JCB 446ZX Wheel Loader Specs front
JCB 446ZX Wheel Loader Specs side
JCB 446ZX Wheel Loader Specs side
JCB 446ZX Wheel Loader Specs back
JCB 446ZX Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.06 ft in

Dimensions

A

Length with Bucket on Ground

26.12 ft in

B

Width Over Tires

8.87 ft in

C

Height to Top of Cab

11.06 ft in

D

Wheelbase

10.83 ft in

E

Ground Clearance

1.55 ft in

F

Hinge Pin - Max Height

13.48 ft in

H

Reach at Max Lift and Dump

3.63 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2257

Engine Model

6CT8.3C

Net Power

185 hp

Gross Power

193 hp

Power Measured @

2200 rpm

Displacement

506.5 cu in

Torque Measured @

1400 rpm

Max Torque

665.3

Aspiration

turbocharged

Operational

Operating Weight

45492.4 lb

Fuel Capacity

84.6 gal

Hydraulic System Fluid Capacity

56.8 gal

Engine Oil Fluid Capacity

5 gal

Cooling System Fluid Capacity

10.6 gal

Transmission Fluid Capacity

9 gal

Front Axle/Diff Fluid Capacity

18.3 gal

Rear Axle/Diff Fluid Capacity

13.5 gal

Static Tipping Weight

23003.1 lb

Turning Radius

21.6 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

70 amps

Rear Axle Oscillation

25 degrees

Tire Size

23.5R25 HXA (L3)

Transmission

Transmission Type

smooth shift powershift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - Forward

23.3 mph

Max Speed - Reverse

15.2 mph

Hydraulic System

Pump Type

twin variable displacement piston pump

Relief Valve Setting

3625

Pump Flow Capacity

43.1 gal/min

Raise Time

5.8 sec

Dump Time

1.2 sec

Lower Time

4.1 sec

Bucket

Breakout Force

38667.2 lb

Dump Clearance at Max Raise

9.1 ft in

Bucket Width

9.4 ft in

Bucket Capacity - heaped

4.1 yd3

Bucket Capacity - struck

3.7 yd3

Dimensions

Length with Bucket on Ground

26.2 ft in

Width Over Tires

8.9 ft in

Height to Top of Cab

11.1 ft in

Ground Clearance

1.6 ft in

Wheelbase

10.9 ft in

Hinge Pin - Max Height

13.5 ft in

Reach at Max Lift and Dump

3.7 ft in
